Sanyo PLC-XT11

MH7-XT1600, MJ7-XT1100
-93-
Electrical Parts List
405 173 9704 TR 2SA1235A1F
Q2061 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q2071 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q2081 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q3866 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q5001 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q5002 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q5051 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q5052 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q5061 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
Q5062 405 014 4509 TR 2SC2412K T146 R
405 014 4608 TR 2SC2412K T146 S
405 015 8704 TR 2SC2812-L6-TB
405 015 8902 TR 2SC2812-L7-TB
405 163 1602 TR 2SC2812N-L6-TB0
405 163 1701 TR 2SC2812N-L7-TB0
405 173 9803 TR 2SC3928A1R
405 173 9902 TR 2SC3928A1S
INTEGRATED CIRCUIT
IC2091 409 395 5902 IC TC7SH00FU-(TE85L)
IC3801 409 395 5902 IC TC7SH00FU-(TE85L)
IC3806 409 380 6303 IC HIN232CB
IC3851 410 457 0100 IC TWM7000-210010
IC3852 410 466 3109 IC TWM7000-170010
410 457 7109 IC UPD78F9801GB-8ES-MC3A
IC5001 409 051 2702 IC TC4052BF(EL)
CAPACITOR
C1041 403 164 0204 CERAMIC 0.1U Z 25V
C1051 403 157 3601 CERAMIC 100P J 50V
C1052 403 157 3601 CERAMIC 100P J 50V
C1053 403 157 3601 CERAMIC 100P J 50V
C1054 403 157 3601 CERAMIC 100P J 50V
C1061 403 157 3601 CERAMIC 100P J 50V
C1062 403 157 3601 CERAMIC 100P J 50V
C1063 403 157 3601 CERAMIC 100P J 50V
C1064 403 157 3601 CERAMIC 100P J 50V
C1071 403 283 6309 CERAMIC 1U Z 10V
C1072 403 304 3300 ELECT 47U M 16V
C1073 403 157 4202 CERAMIC 220P J 50V
C2013 403 149 9208 CERAMIC 0.01U Z 50V
C2031 403 321 2607 ELECT 10U M 16V
C2032 403 164 0204 CERAMIC 0.1U Z 25V
C2033 403 304 3300 ELECT 47U M 16V
C2041 403 321 2607 ELECT 10U M 16V
C2042 403 164 0204 CERAMIC 0.1U Z 25V
C2051 403 321 2607 ELECT 10U M 16V
C2052 403 164 0204 CERAMIC 0.1U Z 25V
C2061 403 321 2607 ELECT 10U M 16V
C2062 403 164 0204 CERAMIC 0.1U Z 25V
C2071 403 164 0204 CERAMIC 0.1U Z 25V
C2072 403 164 0204 CERAMIC 0.1U Z 25V
C2081 403 321 2607 ELECT 10U M 16V
C2082 403 164 0204 CERAMIC 0.1U Z 25V
C2091 403 164 0204 CERAMIC 0.1U Z 25V
C2096 403 229 3508 ELECT 100U M 16V
C2097 403 322 7809 ELECT 220U M 6.3V
C3801 403 283 6309 CERAMIC 1U Z 10V
C3802 403 162 6208 ELECT 1U M 50V
C3808 403 162 6208 ELECT 1U M 50V
C3809 403 162 6208 ELECT 1U M 50V
C3811 403 162 6208 ELECT 1U M 50V
C3812 403 162 6208 ELECT 1U M 50V
C3813 403 283 6309 CERAMIC 1U Z 10V
C3851 403 164 0204 CERAMIC 0.1U Z 25V
C3852 403 164 0204 CERAMIC 0.1U Z 25V
C3853 403 304 3102 ELECT 22U M 16V
C3854 403 164 0204 CERAMIC 0.1U Z 25V
C5001 403 323 8805 CERAMIC 2.2U Z 16V
C5002 403 323 8805 CERAMIC 2.2U Z 16V
C5003 403 323 8805 CERAMIC 2.2U Z 16V
Key No. Part No. Description Key No. Part No. Description
