Sanyo PLC-XT11 Service Manual

MH7-XT1600, MJ7-XT1100
Electrical Parts List
-96-
610 302 5902 ASSY,PWB,CONTROL MC3A
CAPACITOR
C6801 403 164 0204 CERAMIC 0.1U Z 25V
C6802 403 164 0204 CERAMIC 0.1U Z 25V
C6803 403 164 0204 CERAMIC 0.1U Z 25V
C6804 403 164 0204 CERAMIC 0.1U Z 25V
RESISTOR
R6801 401 105 2904 MT-GLAZE 22K JA 1/16W
R6802 401 105 1600 MT-GLAZE 15K JA 1/16W
R6803 401 105 1600 MT-GLAZE 15K JA 1/16W
R6804 401 105 1501 MT-GLAZE 1.5K JA 1/16W
R6806 401 105 5202 MT-GLAZE 470 JA 1/16W
R6807 401 105 1501 MT-GLAZE 1.5K JA 1/16W
R6808 401 105 5202 MT-GLAZE 470 JA 1/16W
R6809 401 105 2904 MT-GLAZE 22K JA 1/16W
R6811 401 105 1600 MT-GLAZE 15K JA 1/16W
R6812 401 105 6001 MT-GLAZE 5.6K JA 1/16W
R6813 401 105 5301 MT-GLAZE 4.7K JA 1/16W
R6814 401 105 3307 MT-GLAZE 2.7K JA 1/16W
R6816 401 105 4106 MT-GLAZE 3.3K JA 1/16W
R6817 401 105 5202 MT-GLAZE 470 JA 1/16W
R6851 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R6852 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R6853 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R6854 401 105 7909 MT-GLAZE 0.000 ZA 1/16W
R6857 401 105 8203 MT-GLAZE 68K JA 1/16W
R6858 401 105 0603 MT-GLAZE 10K JA 1/16W
DIODE
D6801 407 223 0501 ZENER DIODE 02DZ12Y(TPH3)
D6802 407 223 0501 ZENER DIODE 02DZ12Y(TPH3)
D6803 407 223 0501 ZENER DIODE 02DZ12Y(TPH3)
D6804 407 223 0501 ZENER DIODE 02DZ12Y(TPH3)
D6856 407 209 7401 LED SML-210YT-K-T86
407 209 7500 LED SML-210YT T86 L
D6857 407 203 7803 LED SML-210LT T86 M
D6858 407 203 7902 LED SML-210MT T86 M
D6859 407 203 7803 LED SML-210LT T86 M
MISCELLANEOUS
SW6801 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6802 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6803 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6804 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6806 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6807 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6808 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6809 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6811 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6812 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6813 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6814 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6816 645 026 2791 SWITCH,PUSH 1P-1TX1
SW6817 645 026 2791 SWITCH,PUSH 1P-1TX1
645 054 3135 CABLE,MOUSE SRAL
645 054 3142 CABLE,MOUSE SRAL
645 039 7219 CABLE,MOUSE SRAL
645 063 6943 CABLE,USB
645 061 5115 CABLE,USB
645 063 6936 CABLE,USB
610 302 3106 COVER,DUST-MC3A
645 043 9704 ADAPTOR,DVI/VGA
645 057 2999 CABLE,INTERFACE VGA
RC
645 055 8597 ASSY,REMOCON CXLZ
A9901C 610 302 4196 RC-BATTERY LID-CXLZ
OWNER’S MANUAL
(English) 610 308 2318 OWNER'S MANUAL-MH7A
(Germany) 610 308 2325 OWNER'S MANUAL-MH7A-D
(French) 610 308 2332 OWNER'S MANUAL-MH7A-F
(Italy) 610 308 2349 OWNER'S MANUAL-MH7A-I
(Spanish) 610 308 2356 OWNER'S MANUAL-MH7A-E
AC CORD
!(US) 645 054 1162 CORD,POWER-3.0MK
!(EU) 645 054 1155 CORD,POWER-3.0MK
!(UK) 645 054 1148 CORD,POWER-3.138MK
ACCESSORIES
CONROL BOARD
Key No. Part No. Description Key No. Part No. Description
