Sanyo PLC-XT35L

-136-
Mechanical Parts List
KP3-XT3500, KP3-XT35L00
POL
POL
W
V
Red polarized unit (IN)
Green polarized unit (IN)
Blue polarized unit (IN)
Polarized unit (IN)
S04
M05
M09
L03: R
L04: G
L05: B
TH902
L07: R
L08: G
L09: B
Note:
Only the Blue panel assy
provides TH902 and M09.
POL
WV
Note:
L03, L04 and L05 differ with parts according to
type of LCD panel/prism assembly.
M04-1:R
M04-2:G,B
