Sanyo PLC-XT35L

-71-
Electrical Adjustment
Group/
Item
Item Name Function Initial Range Note
1 Spread Spectrum Frequency
200-500 Deviation Default:300 x 100Hz
30KHz Deviation when "300" is set
80 0 - 500
2 Spread Spectrum Amplitude
0-300 Rate Default:100
±0.5% Spectrum Rate when "100" is set
100 0 - 300
Group 210 LampContorl
0 Enable
Luminance Level 1 Data for Dimmer: Dim
Level 1 at the less than the Value
7 0 - 255
1 DIMMER_CTRL_LEVEL2
Luminance Level 2 Data for Dimmer: Dim
Level 2 at the less than the Value
14 0 - 255
2 DIMMER_CTRL_LEVEL3
Luminance Level 3 Data for Dimmer: Dim
Level 3 at the less than the Value
21 0 - 255
3 DIMMER_CTRL_LEVEL4
Luminance Level 4 Data for Dimmer: Dim
Level 4 at the less than the Value
28 0 - 255
4 DIMMER_CTRL_LEVEL5
Luminance Level 5 Data for Dimmer: Dim
Level 5 at the less than the Value
35 0 - 255
5 DIMMER_CTRL_LEVEL6
Luminance Level 6 Data for Dimmer: Dim
Level 6 at the less than the Value
42 0 - 255
6 DIMMER_CTRL_LEVEL7
Luminance Level 7 Data for Dimmer: Dim
Level 7 at the less than the Value
49 0 - 255
7 DIMMER_CTRL_LEVEL8
Luminance Level 8 Data for Dimmer: Dim
Level 8 at the less than the Value
56 0 - 255
8 DIMMER_CTRL_LEVEL9
Luminance Level 9 Data for Dimmer: Dim
Level 9 at the less than the Value
63 0 - 255
9 DIMMER_CTRL_LEVEL10
Luminance Level 10 Data for Dimmer: Dim
Level 10 at the less than the Value
70 0 - 255
10 DIMMER_CTRL_LEVEL11
Luminance Level 11 Data for Dimmer: Dim
Level 11 at the less than the Value
77 0 - 255
11 DIMMER_CTRL_LEVEL12
Luminance Level 12 Data for Dimmer: Dim
Level 12 at the less than the Value
84 0 - 255
12 DIMMER_CTRL_LEVEL13
Luminance Level 13 Data for Dimmer: Dim
Level 13 at the less than the Value
91 0 - 255
13 DIMMER_CTRL_LEVEL14
Luminance Level 14 Data for Dimmer: Dim
Level 14 at the less than the Value
98 0 - 255
14 DIMMER_CTRL_LEVEL15
Luminance Level 15 Data for Dimmer: Dim
Level 15 at the less than the Value
105 0 - 255
15 DIMMER_AVERAGE_POINT Luminance Data Avarage Point for Mimmer 4 0 - 16
16 DIMMER_AVERAGE_DATA Luminance Data Avarage Value for Dimmer - - * Read only
17 DIMMER_LEVEL_AUTO Current Dimmer Leverl - - * Read only
18 DIMMER_LEVEL_NORMAL Normal Dimmer Level 0 - 14
19 DIMMER_LEVEL_ECO Eco Dimmer Level 0 - 14
20 Lamp check enable 0 - 1
0: Lamp Failure Detection OFF (White 50%
Back), 1 : ON (Blue 100% Back)
21 VOLTAGE_LEVEL Lamp Voltage Unit: 8bit(Raw Data) * Read only
22 DIMMER_LEVEL_HIGH
Dimmer Level HIGH
0 - 15
Group 220 Projector Error History * Refer to Error History Log
0 Warning_Log_1 0 0 ~ 32767 Latest error log
~ : : : :
49 Warning_Log_50 0 0 ~ 32767 50th Error log
50 Warning_Log Reset 0 0 ~ 10
Projector Error Hisrory Log is creared when
the value is set to "10".
Group 250 Fan Voltage Adjustment
0 Fan1 Min Adjust (DAC) Fan DAC Output Adjustment 60 0~255
* Fan voltage adjustment
1 Fan1 Max Adjust (DAC) Adjust DAC-Fan Voltage tolelance 210 0~255
2 Fan2 Min Adjust (DAC) * Lamp Mode: Eco 60 0~255
3 Fan2 Max Adjust (DAC)
(DACmax - DACmin) / (Volmax - Volmin) *
Volnow - Volmin) + DACmin
210 0~255
4 Fan3 Min Adjust (DAC) 60 0~255
5 Fan3 Max Adjust (DAC) 210 0~255
6 Fan4 Min Adjust * Not used
7 Fan4 Max Adjust * Not used
Group 251 Fan Clogging Detection Setting
Normal Highland
0 Filter Warning Calibration
Clogging Detect Auto Offset Adj.
* OK Displayed after finished
0 0~1 * Filter calibration adjustment
