Electrical Adjustment
Group/
Item
Item Name Function Initial Range Note
1 Filter Warning Offset Point 0
Fan Cloggle Detect Offset value. (Freq.)
* The value is set automatially after Caribra-
tion
1731 1812 0000~9999
2 Filter Warning Offset Point 1 2686 2818 0000~9999
3 Filter Warning Offset Point 2 3456 3598 0000~9999
4 Filter Warning Offset Point 3 4139 4288 0000~9999
5 Filter Warning Offset Point 4 4728 4948 0000~9999
6 Filter Warning Offset Point 5 5221 5522 0000~9999
7 Filter Warning Offset Point 6 5607 5988 0000~9999
8 Filter Warning Offset Point 7 5899 6332 0000~9999
9 * Not used
10 * Not used
11 * Not used
12 * Not used
13 Filter Warning Time Cloggle Det. Time(min) 3 0 - 10
14 Fan-Add Filter Level 1 Additional Fan Freq. at Clogging Level1 (rpm) 1000 0000-9990
15 Fan-Add Filter Level 2 Additional Fan Freq. at Clogging Level2 (rpm) 2000 0000-9990
16 Filter Warning Calibration Range
Tolelance at Auto Adjustment
(1:±5rpm 2:±10rpm 10:±50rpm)
1 0~10
17 Filter Warning Calibration Time Time to OK at Auto calibration (sec) 2 1~10
18 Filter Warning Calibration Error Log
Log of Auto calibration (Read only)
0: No Error
100-111: Fan Min Adj Error
200~211: Out of Torelance
255: Auto calibration not Executed
255 0~255
19
Filter Warning High Land Calibration
Error Log
High Land Calibration Error Log (Read only)
0: No Error
50: Cancelling Adj.
100-111: Fan Min Adj Error
200~211: Out of Torelance
255: Auto calibration not Executed
255 0~255
20 Filter Warning Calibration Temp
External Temp. at calibration execution(x10)
*Read only
260 260 -
21
Filter Warning Inclination Rpm
(to 26ºC)
Increase value of Threshold Rotation when
Temp increase 10ºC
(Lower then 26ºC Ext. temp)
80 0000-9999
22
Filter Warning Inclination Rpm
(over 26ºC)
Increase value of Threshold Rotation when
Temp increase 10ºC
(Higher then 26ºC Ext. temp)
90 0000-9999
23 Filter Warning Add Offset Rpm
Rotation correction due to Temp.
*Read only
- -
Group 252 Fan Option
0 Fan Max Switch
0:Normal
1:Max Fixed (13.5V)
* HighLand Set is disable when setting Fan
Max
0 0-5
1 Safety Switch
Safety Exam FAN Control Switch
(0:Normal, 1:High Min, 2:High Max, 3:Normal
Min, 4:Normal Max, 5:Eco Min,6:Eco Max)
0 0~6
2 Fan Manual Switch
Fan Manual SW
(0:Auto 1:Mamual Adj)
0-3
3 Fan1 Manual Voltage
Fan Voltage Manual Adj Mode (0.1V)
* Effective only Fan Manual Switch = 1
0-255
4 Fan2 Manual Voltage 0-255
5 Fan3 Manual Voltage 0-255
6 Fan4 Manual Set
PWM Duty Ratio Manual Adj Mode
* Effective only Fan Manual Switch = 1
0-511
7 DAC OUT Stability
DAC Output update period setting
1: every second, 2 sec, 3: 3sec.
2 0-10
