-74-
Electrical Adjustment
Group/
Item
Item Name Function Initial Range Note
Group 255 Fan Start/Cooling Setting
0 Fan1 Initial Volt
Fan Start Voltage (0.1V)
55 0-255
1 Fan2 Initial Volt 65 0-255
2 Fan3 Initial Volt 35 0-255
3 Fan4 Initial Pulse 700 0-4095
4 * Not used
5 * Not used
6 * Not used
7 * Not used
8 Cooling Time
Cooling Time (x30sec)
1:30sec 3:90sec 15:450sec
3 1-15
9 * Not used
10 Temp Error Cooling Time
Cooling Time at Temp Error (x30sec)
1:30sec 3:90sec 15:450sec
3 1-15
11 OnStart Cooling Start Threshold 38 0-100
12 After shutdown cooling Cooling After Shut Down (0:No 1:Yes) 1 0-1
Group 256 Fan Lamp Voltage Down Setting
0 Lamp Voltage Current Lamp Voltage (0.1V)(Read only) - 0-255
1 Lamp Vol Threshold
Threshold to judge Lamp Voltage Down ( V×
10)
60 30-90
2 Fan1 Speed Gain
Additional Fan Speed of Min at Lamp Voltage
Down (rpm)
300 0-1500
3 Fan2 Speed Gain 300 0-1500
4 Fan3 Speed Gain 300 0-1500
5 Fan4 Speed Gain 300 0-1500
Group 257 Fan Dimmer Setting
0 Dimmer Average Check Period
Dimmer Avarage measurement Time
(0:10sec, 1:30sec, 2:6sec, 90sec...10:300sec)
1 0-10
1 Dimmer Average Dimmer Avarage Value (Read only) -
2 Last Voltage Difference -
3 Voltate Difference Goal -
Group 258 * Not used
Group 260 Auto Calibration (Commn) * Auto Calibration
0 Execute Calibration 0 0 - 1
Executes Auto-Calibration when changiing
the Value (PC White 100%)
* Signal auto calibration
1 Loop Count Maximum Execution Times (OFFSET->GAIN) 3 1 - 30
2 Auto Status Result of Auto-Calibration (Last Memory) 0 0 / 1 / 9 0: OK, 1: Adjusting,9: Error * ReadOnly
3 AutoWait Wait Value for each setting 3 1 - 20
4 CHECK -Tolelance Torelance of OFFSET 1 1 - 255
Group 261 Auto Calibration (RGB)
0 OFFSET AREA H START Black Level Acquiring Area H-Start Position 975 0 - 1000
1 OFFSET AREA V START Black Level Acquiring Area V-Start Position 500 0 - 1000
2 GAIN AREA H START White Level Acquiring Area H-Start Position 25 0 - 1000
3 GAIN AREA V START White Level Acquiring Area V-Start Position 500 0 - 1000
4 Image AREA H WIDTH Black/White Level Acquiring Area 13 0 - 4095
5 Image AREA V HIGHT Black/White Level Acquiring Area Height 9 0 - 4095
6 OFFSET target Target Value of Black Level Adj. 3 0 - 127
7 OFFSET torelance Torelance of Black Level Adj. 1 1 - 127
8 GAIN target Target Value of White Level Adj. 238 0 - 255
9 GAIN torelance Torelance of White Level Adj. 1 1 - 255
Group 263 Auto Calibration (CVBS/SVIDEO) CXA3815
0 Y Image Area Start X Y Acquiring Area H-Start Position 25 0 - 1000
1 Y Image Area Start Y Y Acquiring Area V-Start Position 200 0 - 1000
6 Image Area H Width Image Level Acquiring Area 13 0 - 4095
7 Image Area V Hight Image Level Acquiring Area Height 9 0 - 4095
8 Y Target Level Target Value of Y Level Adj. 200 0 - 255
11 Gain Tolerance Torelance of Level Adj. 1 0 - 255
Group 265 Auto Calibration (YCbCr) CXA3815
6 Y - GAIN AREA H START Y 25 0 - 1000
7 Y - GAIN AREA V START 500 0 - 1000
To Next Page
