Key No. Part No. Description Key No. Part No. Description
KF5-XU35000 , KA5-XU30000
Electrical Parts List
-72-
R643 301 150 5918 MT-GLAZE 10K JA 1/10W
R644 301 150 5918 MT-GLAZE 10K JA 1/10W
R646 301 256 7212 MT-GLAZE 18K JA 1/10W
R648 301 256 7212 MT-GLAZE 18K JA 1/10W
R651 301 150 5918 MT-GLAZE 10K JA 1/10W
R652 301 292 1915 MT-GLAZE 22 FA 1/2W
R662 301 152 3219 MT-GLAZE 330 JA 1/10W
R671 301 256 7618 MT-GLAZE 3.9K JA 1/10W
R672 301 150 6212 MT-GLAZE 1K JA 1/10W
R673 301 264 2919 MT-GLAZE 12K FA 1/10W
R674 301 264 7518 MT-GLAZE 2.7K FA 1/10W
R675 301 150 6212 MT-GLAZE 1K JA 1/10W
R676 301 264 2810 MT-GLAZE 1.2K FA 1/10W
R683 301 265 0211 MT-GLAZE 390 FA 1/10W
R684 301 264 9314 MT-GLAZE 3.3K FA 1/10W
VARIABLE RESISTOR
!VR621 645 095 2579 VR,SEMI,1K N
TRANSFORMER
!T651 645 097 6483 TRANS,POWER,PULSE
COIL
!L611 645 098 0473 LINE FILTER
L612 945 077 6565 INDUCTOR,900U
945 084 0273 INDUCTOR,1400U
L613 910 244 3975 CORE
L614 910 244 3975 CORE
L661 910 244 3975 CORE
L662 910 244 3975 CORE
L663 945 041 1978 INDUCTOR,330 OHM
DIODE
D611 307 191 3903 DIODE FML-G16S
D611D 645 098 1715 FERRITE
D611E 645 098 1715 FERRITE
D613 307 149 0810 DIODE 1SS355-TE-17
D632 307 247 8827 DIODE RF101L2S
D633 307 146 8116 DIODE EG01C
D651 307 247 8827 DIODE RF101L2S
D661 407 261 9504 DIODE YG862C10R
D662 307 222 9607 DIODE FMB-2306
307 202 9801 DIODE FMB-26L
307 253 7504 DIODE RB085T-60
307 250 2403 DIODE RB225T-60
D663 307 247 8827 DIODE RF101L2S
307 190 4119 DIODE SFPL-52V
D664 307 210 5416 DIODE RB551V-30-TE-17
DB611 307 202 7708 DIODE D10XB60
MISCELLANEOUS
!F631 324 006 1305 FUSE 250V 2.5A
Q611F 645 098 1715 FERRITE
!PC661 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7)
!PC671 307 223 7315 PC TLP421F(D4-GB-TP4)
307 223 8312 PC TLP421F(D4-GR-TP4)
407 265 7813 PC TLP781F(D4-GB-TP7)
PTH611 308 037 5501 THERMISTOR NTPDB5R0LDHB0
PTH641 408 062 4606 TH PRF18BD471QB1RB
ZD631 307 206 5413 ZD UDZS-TE-178.2B
655 002 7603 ASSY,PWB,FILTER KG5AC
CAPACITOR
!C601 404 117 6403 MT-POLYEST 1U K 275V
404 117 8902 MT-POLYEST 1U K 310V
!C602 404 117 6403 MT-POLYEST 1U K 275V
404 117 8902 MT-POLYEST 1U K 310V
!C603 304 073 3907 CERAMIC 1000P K 250V
!C604 304 073 3907 CERAMIC 1000P K 250V
RESISTOR
!R601 301 287 6215 MT-GLAZE 240K JA 1W
!R602 301 287 6215 MT-GLAZE 240K JA 1W
VARIABLE RESISTOR
!VA601 407 255 6304 VARISTOR MYG3-14K300ZT
408 061 9701 VARISTOR S14K300E2S5M4,2
MISCELLANEOUS
!LF601 645 093 1765 SOCKET,INLET AC 3P
!LF601H 610 343 1475 HOLDER POWER AC-KG5AC
!F601 423 034 4101 FUSE 250V 6.3A
323 021 7804 FUSE 250V 6.3A
FOR KF5-XU35000
655 002 8501 ASSY,PWB,MIAN KF5AC
FOR KA5-XU30000
655 002 9300 ASSY,PWB,MAIN KA5AC
TRANSISTOR
Q1001 406 021 7804 TR 2SC4617
Q1002 406 021 7804 TR 2SC4617
Q1003 305 217 7815 TR HN1B04FE-Y TE85L
Q1004 305 217 7815 TR HN1B04FE-Y TE85L
Q1005 406 021 7804 TR 2SC4617
Q1006 305 217 7815 TR HN1B04FE-Y TE85L
Q1007 406 021 7804 TR 2SC4617
Q1008 406 021 7804 TR 2SC4617
Q1062 406 021 7804 TR 2SC4617
Q1421 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q1422 406 021 7804 TR 2SC4617
Q2011 406 021 7804 TR 2SC4617
Q2021 406 021 7804 TR 2SC4617
Q2031 406 021 7804 TR 2SC4617
Q3051 406 021 7804 TR 2SC4617
Q3582 305 217 6917 TR TPC6107 TE85L
Q3583 406 021 7804 TR 2SC4617
Q3601 406 021 7804 TR 2SC4617
Q3801 305 191 5814 TR 3LN01C-TB-E
Q4012 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
Q4014 305 217 7815 TR HN1B04FE-Y TE85L
Q4015 305 217 7815 TR HN1B04FE-Y TE85L
Q4016 305 217 7815 TR HN1B04FE-Y TE85L
Q5031 405 221 7914 TR HN1C01FE-Y
Q5033 406 021 7804 TR 2SC4617
Q5035 405 221 7914 TR HN1C01FE-Y
Q5061 405 221 7914 TR HN1C01FE-Y
Q5062 405 221 7914 TR HN1C01FE-Y
Q5306 406 021 7804 TR 2SC4617
Q5336 305 134 5928 TR 2SA1037AK-T146-R
