Sanyo PLC-XU350 User Manual

KF5-XU35000 , KA5-XU30000
-71-
Electrical Parts List
Electrical Parts List
Note: Parts order must contain Chassis No., Part No., and Descriptions.
Key No. Part No. Description Key No. Part No. Description
ASSEMBLED BOARD
FOR KF5-XU35000
!A601 655 002 7610 ASSY,PWB,POWER KG5AC
!A602 655 002 7603 ASSY,PWB,FILTER KG5AC
!A1000 655 002 8501 ASSY,PWB,MIAN KF5AC
!A1001 655 002 8495 ASSY,PWB,AV KF5AC
!A2800 655 002 8488 ASSY,PWB,R/C KF5AC
!A8700 655 002 8471 ASSY,PWB,ID CONNECT-1 KF5AC
FOR KA5-XU30000
!A601 655 002 7610 ASSY,PWB,POWER KG5AC
!A602 655 002 7603 ASSY,PWB,FILTER KG5AC
!A1000 655 002 9300 ASSY,PWB,MIAN KA5AC
!A1001 655 002 8495 ASSY,PWB,AV KF5AC
!A2800 655 002 8488 ASSY,PWB,R/C KF5AC
!A8700 655 002 8471 ASSY,PWB,ID CONNECT-1 KF5AC
OUT OF CIRCUIT BOARD
L601 945 033 2228 FERRITE
!LP900 610 343 2069 POA-LMP131
!A901 645 099 2575 BALLAST
A901A 610 344 5335 CABLE,BALLAST KG5AC
!FN901 645 099 5217 MOTOR,BLW DC 1.92W
!FN902 645 099 6160 MOTOR,FAN DC 3.36W
!FN903 645 099 6832 MOTOR,BLW DC 3.0W
!FN904 645 099 6849 MOTOR,BLW DC 3.0W
!FN905 645 099 6832 MOTOR,BLW DC 3.0W
!FN906 645 099 6856 MOTOR,FAN DC 3.36W
!SP901 652 002 4397 SPEAKER,8
!SW901 645 097 3925 SWITCH,MICRO 1P-2T
!SW902 652 002 8852 THERMAL
Z6B&6C 652 002 8470 ASSY,WIRE
Z9502&99 610 335 3111 CORD,SHIELD 1P
655 002 7610 ASSY,PWB,POWER KG5AC
TRANSISTOR
Q611 305 146 6405 TR 2SK2837
Q641 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q642 305 014 4512 TR 2SC2412K T146 R
305 014 4611 TR 2SC2412K T146 S
305 015 8727 TR 2SC2812-L6-TB
305 015 8925 TR 2SC2812-L7-TB
305 163 1615 TR 2SC2812N-L6-TB0
305 173 9816 TR 2SC3928A1R
305 173 9915 TR 2SC3928A1S
Q643 305 217 6600 TR 2SK3934
Q651 305 134 5928 TR 2SA1037AK-T146-R
305 147 2218 TR 2SA1037AK-S-T146
305 173 9618 TR 2SA1235A1E
305 173 9717 TR 2SA1235A1F
405 220 3115 TR ISA1235AC1E
405 220 3016 TR ISA1235AC1F
INTEGRATED CIRCUIT
IC621 409 690 7918 IC FA5550N
IC631 309 653 7405 IC MR4010-7101
IC671 409 692 2515 IC TA76L431FB
CAPACITOR
C611 303 222 1326 CERAMIC 1000P K 1K
304 084 6300 CERAMIC 1000P K 1K
C612 303 222 1326 CERAMIC 1000P K 1K
304 084 6300 CERAMIC 1000P K 1K
C613 303 451 4119 MT-POLYEST 1U K 450V
C614 303 451 4119 MT-POLYEST 1U K 450V
C615 404 118 3609 ELECT 150U M 420V
C621 303 336 3510 CERAMIC 0.47U K 16V
C622 304 091 4504 CERAMIC 0.047U K 50V
C623 304 090 1207 CERAMIC 0.01U K 50V
C625 304 090 1207 CERAMIC 0.01U K 50V
C626 303 396 9613 CERAMIC 1U K 25V
C627 304 091 3309 CERAMIC 2200P K 50V
C631 303 157 4215 CERAMIC 220P J 50V
C632 404 111 2401 CERAMIC 680P K 2K
C633 303 265 3216 CERAMIC 1000P J 50V
C634 304 091 3309 CERAMIC 2200P K 50V
C641 304 091 2609 CERAMIC 0.1U K 50V
C644 303 417 9912 CERAMIC 4.7U K 25V
C651 304 097 0005 ELECT 100U M 25V
C653 303 367 0410 CERAMIC 0.1U K 50V
303 370 1510 CERAMIC 0.1U K 50V
C661 303 445 4405 ELECT 1800U M 25V
C662 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C663 303 367 0410 CERAMIC 0.1U K 50V
304 091 2609 CERAMIC 0.1U K 50V
C664 303 429 6718 ELECT 1500U M 10V
C665 303 409 9913 ELECT 470U M 16V
C671 304 091 2609 CERAMIC 0.1U K 50V
C691 304 073 4508 CERAMIC 2200P K 250V
C692 304 073 4508 CERAMIC 2200P K 250V
RESISTOR
R611 401 353 0311 MT-GLAZE 430K JA 1/3W
R612 401 353 0212 MT-GLAZE 360K JA 1/3W
R613 301 256 6314 MT-GLAZE 47K JA 1/10W
R614 302 106 5508 RESISTER 0.075 KB 5W
R615 301 188 3313 MT-GLAZE 680K JA 1/4W
R616 301 188 3313 MT-GLAZE 680K JA 1/4W
R621 301 265 5711 MT-GLAZE 8.2K FA 1/10W
R622 301 264 9215 MT-GLAZE 330 FA 1/10W
R624 301 162 2912 MT-GLAZE 220 JA 1/10W
R625 301 256 5614 MT-GLAZE 47 JA 1/10W
R626 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R627 301 150 5918 MT-GLAZE 10K JA 1/10W
R628 301 150 5918 MT-GLAZE 10K JA 1/10W
R629 301 255 7312 MT-GLAZE 510K JA 1/10W
R631 301 255 7718 MT-GLAZE 11K JA 1/10W
R633 301 150 6014 MT-GLAZE 0.000 ZA 1/10W
R634 301 256 1715 MT-GLAZE 33K JA 1/10W
R635 302 099 6308 OXIDE-MT 0.39JA 1W
R636 301 162 3018 MT-GLAZE 22K JA 1/10W
R641 301 150 5918 MT-GLAZE 10K JA 1/10W
R642 301 256 6611 MT-GLAZE 68K JA 1/10W
