Sanyo PLC-XU75 Service Manual

-43-
Group/
Item
ITEM NAME FUNCTION INITIAL RANGE NOTE
5 Temp A Warning (Normal)
Temp. A to judge the Temp Error at Normal
(Room)
42 43 33 33 30-100
6 Temp B Warning (Normal)
Temp. B to judge the Temp Error at Normal
(Panel)
62 61 56 64 30-100
7 Temp C Warning (Normal)
Temp. C to judge the Temp Error at Normal
(Lamp)
69 68 66 63 30-100
8 Temp B-A Warning (Normal)
Temp. B-A to judge the Temp Error at Normal
(Clogging Det.)
100 100 100 100 0-100
9 Temp C-A Warning (Normal)
Temp. C-A to judge the Temp Error at Normal
(Clogging Det.)
100 100 100 100 0-100
10 Temp A Warning (Eco) Temp. A to judge the Temp Error at Eco (Room)
44 43 37 36 30-100
11 Temp B Warning (Eco) Temp. B to judge the Temp Error at Eco (Panel)
58 58 56 55 30-100
12 Temp C Warning (Eco) Temp. C to judge the Temp Error at Eco (Lamp)
65 62 62 61 30-100
13 Temp B-A Warning (Eco)
Temp. B-A to judge the Temp Error at Normal
(Clogging Det.)
100 100 100 100 0-100
14 Temp C-A Warning (Eco)
Temp. C-A to judge the Temp Error at Normal
(Clogging Det.)
100 100 100 100 0-100
15 Temp A Warning Offset (Temp)
Offset of Temp Error (Temp.)
Error Setting Value is increased XC at the
below condition
* Standby
* Right to turn on the lamp
*Right to change the Lamp mode
5 0-100
16 Temp B Warning Offset (Temp)
5 0-100
17 Temp C Warning Offset (Temp)
5 0-100
18 Temp B-A Warning Offset (Temp)
0 0-100
19 Temp C-A Warning Offset (Temp)
0 0-100
20 Temp A Warning Offset (Time)
Offset of Temp Error (Minutes)
Error Setting Value is increased X minute at
the below condition
* Standby
* Right to turn on the lamp
*Right to change the Lamp mode
3 0-5
21 Temp B Warning Offset (Time)
3 0-5
22 Temp C Warning Offset (Time)
3 0-5
23 Temp B-A Warning Offset (Time)
3 0-5
24 Temp C-A Warning Offset (Time)
3 0-5
PLC-XU78
Group 254 Fan Control Range Setting (Temp./Voltage) Normal Ceiling
HiLand-
Normal
HiLand-
Ceiling
0 Not used
9999
1 Not used
9999
2 Not used
9999
3 Not used
9999
4 Not used
9999
5 Not used
9999
6 Not used
9999
7 Not used
9999
8 Not used
9999
9 Not used
9999
10 Normal Fan Control Min Temp
Temp Senser Control Start/End Tem.p at
Normal
28 28 20 20 20-100
11 Normal Fan Control Max Temp
36 37 20 20 20-100
12 Normal Fan1 Min
Fan voltage value at Normal (unit: 0.1V)
65 70 120 125 0-255
13 Normal Fan1 Max
120 125 120 125 0-255
14 Normal Fan2 Min
80 95 125 125 0-255
15 Normal Fan2 Max
125 125 125 125 0-255
16 Not used
9999 9999
17 Not used
9999 9999
18 Not used
9999 9999
19 Not used
9999 9999
20 Eco Fan Control Min Temp
Temp Senser Control Start/End Tem.p at Eco
28 28 20 20 20-100
21 Eco Fan Control Max Temp
37 37 20 20 20-100
22 Eco Fan1 Min
Fan voltage value at Eco (unit: 0.1V)
50 55 100 105 0-255
23 Eco Fan1 Max
100 105 100 105 0-255
24 Eco Fan2 Min
60 65 75 80 0-255
25 Eco Fan2 Max
75 80 75 80 0-255
26 Not used
9999 9999
27 Not used
9999 9999
28 Not used
9999 9999
29 Not used
9999 9999
PLC-XU75
Group 254 Fan Control Range Setting (Temp./Voltage) Normal Ceiling
HiLand-
Normal
HiLand-
Ceiling
0 Not used
9999
1 Not used
9999
2 Not used
9999
3 Not used
9999
4 Not used
9999
5 Not used
9999
6 Not used
9999
