-44-
Group/
Item
ITEM NAME FUNCTION INITIAL RANGE NOTE
7 Not used 9999
8 Not used
9999
9 Not used
9999
10 Normal Fan Control Min Temp
Temp Senser Control Start/End Tem.p at
Normal
29 30 20 20 20-100
11 Normal Fan Control Max Temp
37 37 20 20 20-100
12 Normal Fan1 Min
Fan voltage value at Normal (unit: 0.1V)
60 60 110 110 0-255
13 Normal Fan1 Max
110 110 110 110 0-255
14 Normal Fan2 Min
75 77 110 110 0-255
15 Normal Fan2 Max
110 110 110 110 0-255
16 Not used
9999 9999
17 Not used
9999 9999
18 Not used
9999 9999
19 Not used
9999 9999
20 Eco Fan Control Min Temp
Temp Senser Control Start/End Tem.p at Eco
29 29 20 20 20-100
21 Eco Fan Control Max Temp
38 37 20 20 20-100
22 Eco Fan1 Min
Fan voltage value at Eco (unit: 0.1V)
50 50 90 90 0-255
23 Eco Fan1 Max
90 90 90 90 0-255
24 Eco Fan2 Min
60 65 75 75 0-255
25 Eco Fan2 Max
75 80 75 75 0-255
26 Not used
9999 9999
27 Not used
9999 9999
28 Not used
9999 9999
29 Not used
9999 9999
Group 255 Fan Start/Cooling Setting
0 Fan1 Initial Volt
Fan Start Voltage (0.1V)
55 0-255
1 Fan2 Initial Volt
55 0-255
2 Not used
9999
3 Not used
9999
4 Fan1 Cooling Speed
Fan Voltage at Power Off (0.1V)
130 0-255
5 Fan2 Cooling Speed 130 0-255
6 Not used 9999
7 Not used 9999
8 Cooling Time L1
Cooling Time stting at Fan Mode L1 (x 30 sec)
1: 30, 3: 90, 15: 450 sec.
2 1-15
9 Cooling Time L2
Cooling Time stting at Fan Mode L2 (x 30 sec)
1: 30, 3: 90, 15: 450 sec.
3 1-15
10 Temp Error Cooling Time Cooling Time setting at Temp Erro (x 30 sec) 3 1-15
11 OnStart Cooling Start Threshold 38 0-100
12 After shutdown cooling Cooling after shutdown (0: No, 1: Yes) 1 0-1
Group 256 Fan Lamp Voltage Down Setting
0 Lamp Voltage Current Lamp Voltage (0.1V)(Read only)
- 0-255
1 Lamp Vol Threshold
Threshold to judge Lamp Voltage Down ( V×
10)
0 30-90
2 Fan1 Speed Gain
Additional Fan Speed of Min at Lamp Voltage
Down (unit: 0.1V)
10 0-255
3 Fan2 Speed Gain
10 0-255
4 Not used
9999
5 Not used
9999
Group 257 Fan Dimmer Setting
0 Dimmer Average Check Period
Dimmer Avarage measurement Time
(0:10sec, 1:30sec, 2:6sec, 90sec...10:300sec)
1 0-10
1 Dimmer Average Dimmer Avarage Value (Read only)
2 Last Voltage Difference (Read only)
3 Voltage Difference Goal (Read only)
Group 260 Auto Calibration (Commn) * Auto Calibration
0 Execute Calibration 0 0 - 1
Executes Auto-Calibration when changiing
the Value (PC White 100%)
1 Loop Count Maximum Execution Times (OFFSET->GAIN) 10 1 - 30
2 Auto Status Result of Auto-Calibration (Last Memory) 0 0 / 1 / 9 0: OK, 1: Adjusting,9: Error * ReadOnly
3 AutoWait Wait Value for each setting 1 1 - 20
4 CHECK -Tolelance Torelance of OFFSET 2 1 - 255
Group 261 Auto Calibration (RGB)
0 OFFSET AREA H START Black Level Acquiring Area H-Start Position 975 0 - 1000
1 OFFSET AREA V START Black Level Acquiring Area V-Start Position 500 0 - 1000
2 GAIN AREA H START White Level Acquiring Area H-Start Position 25 0 - 1000
3 GAIN AREA V START White Level Acquiring Area V-Start Position 500 0 - 1000
4 Image AREA H WIDTH Black/White Level Acquiring Area 13 0 - 4095
To Next Page
