Sanyo SPW-C1503GDYH8 User Manual

Control of W-ECO MULTI SYSTEM
3
TD831077
III - 50
■ How to check overlapping of central address No.
a Press the TEST / CHK and ZONE buttons at the same time for more than 4 seconds.
SETTING
and CODE No. C1 will flash.
b Select CODE No. C3 by pressing
, (SET TEMP) button and press the SET button.
C3 changes from flashing to ON state and
SETTING
will flash. Then auto. overlap checking will start.
c If C3 changes from ON to flashing and
SETTING
changes from flashing to ON, there is no overlapping. Then finally,
complete the auto. overlap checking mode by pressing the TEST / CHK button.
d If some of GROUP No., ZONE No. and UNIT No. flash, you should try again the zone registration.
1 Select CODE No. C1 by pressing
, (SET TEMP) button and press the SET button.
2 Select the flashing GROUP No. with ZONE and GROUP button.
Then press the CL button and re-select the ZONE, GROUP and UNIT No.
3 Then finally, complete the auto. overlap checking mode by pressing the TEST / CHK button.
2. Optional Controller (system controller)
SET CL
MODE
FAN SPEED
FLAP
SET TEMP.
SELECT
CENTRAL CTRL
GROUP
ZONE
R.C. No.
UNIT No.
No.
CODE
ZONE
19
2
3
4
6
ON
OFF
•
•
TEST / CHK
ALL / ZONE / GR
SETTING
0205_M_I
Registed ZONE and GROUP
No. are displayed.
In case of No-registed,
number is not displayed.
In case of registed, UNIT No.
will be displayed.
: Selected GROUP No.
in case of No-registed.
