Sanyo SPW-C1503GDYH8 User Manual

IV - 77
TD831077
4
W-ECO MULTI SYSTEM Unit Specifications
6-4. Noise criterion curves
6. Ceiling Mounted Type
MODEL : SPW-TR183GH56
SOUND LEVEL : HIGH 36 dB(A), NC 31
LOW 30 dB(A), NC 23
CONDITION : Distance 1 m, Under the unit 1 m
SOURCE : 220 - 230 - 240 V, 1 Phase, 50 Hz
MODEL : SPW-TR253GH56
SOUND LEVEL : HIGH 39 dB(A), NC 34
LOW 34 dB(A), NC 26
CONDITION : Distance 1 m, Under the unit 1 m
SOURCE : 220 - 230 - 240 V, 1 Phase, 50 Hz
MODEL : SPW-TR363GH56
SOUND LEVEL : HIGH 42 dB(A), NC 36
LOW 35 dB(A), NC 28
CONDITION : Distance 1 m, Under the unit 1 m
SOURCE : 220 - 230 - 240 V, 1 Phase, 50 Hz
MODEL : SPW-TR483GH56
SOUND LEVEL : HIGH 44 dB(A), NC 38
LOW 37 dB(A), NC 31
CONDITION : Distance 1 m, Under the unit 1 m
SOURCE : 220 - 230 - 240 V, 1 Phase, 50 Hz
60
50
40
30
20
10
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 µbar)
63 125 250 500 1000 2000 4000 8000
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
BAND CENTER FREQUENCIES, Hz
NC-20
NC-40
NC-50
NC-30
1220_X_I
60
50
40
30
20
10
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 µbar)
63 125 250 500 1000 2000 4000 8000
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
BAND CENTER FREQUENCIES, Hz
NC-20
NC-40
NC-50
NC-30
1221_X_I
60
50
40
30
20
10
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 µbar)
63 125 250 500 1000 2000 4000 8000
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
BAND CENTER FREQUENCIES, Hz
NC-40
NC-50
NC-30
1222_X_I
NC-20
1223_X_I
60
50
40
30
20
10
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 µbar)
63 125 250 500 1000 2000 4000 8000
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
BAND CENTER FREQUENCIES, Hz
NC-40
NC-50
NC-30
NC-20
