Sanyo SPW-C1503GDYH8 User Manual

W-ECO MULTI SYSTEM Unit Specifications
IV - 124
TD831077
4
9. Floor-Standing Type (F Type)
9-4. Noise criterion curves
MODEL : SPW-FR123GH56
SPW-F123GH56
SOUND LEVEL : HIGH 39 dB(A), NC 33
LOW 29 dB(A), NC 23
CONDITION : In front of the unit 1 m, HEIGHT 1 m
SOURCE : 220 - 230 - 240 V, 1 Phase, 50 Hz
MODEL : SPW-FR93GH56
SPW-F93GH56
SOUND LEVEL : HIGH 33 dB(A), NC 27
LOW 28 dB(A), NC 23
CONDITION : In front of the unit 1 m, HEIGHT 1 m
SOURCE : 220 - 230 - 240 V, 1 Phase, 50 Hz
MODEL : SPW-FR183GH56
SPW-F183GH56
SOUND LEVEL : HIGH 39 dB(A), NC 34
LOW 31 dB(A), NC 26
CONDITION : In front of the unit 1 m, HEIGHT 1 m
SOURCE : 220 - 230 - 240 V, 1 Phase, 50 Hz
MODEL : SPW-FR253GH56
SPW-F253GH56
SOUND LEVEL : HIGH 41 dB(A), NC 37
LOW 35 dB(A), NC 30
CONDITION : In front of the unit 1 m, HEIGHT 1 m
SOURCE : 220 - 230 - 240 V, 1 Phase, 50 Hz
0834_V_I
60
50
40
30
20
10
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
63 125 250 500 1000 2000 4000 8000
BAND CENTER FREQUENCIES, Hz
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 µbar)
NC-50
NC-40
NC-30
NC-20
0835_V_I
60
50
40
30
20
10
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
63 125 250 500 1000 2000 4000 8000
BAND CENTER FREQUENCIES, Hz
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 µbar)
NC-50
NC-40
NC-30
NC-20
0836_V_I
60
50
40
30
20
10
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
63 125 250 500 1000 2000 4000 8000
BAND CENTER FREQUENCIES, Hz
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 µbar)
NC-50
NC-40
NC-30
NC-20
0837_V_I
60
50
40
30
20
10
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
63 125 250 500 1000 2000 4000 8000
BAND CENTER FREQUENCIES, Hz
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 µbar)
NC-50
NC-40
NC-30
NC-20
