1
TD831077
I-14
Outline of W-ECO MULTI SYSTEM
Super-slim 19.8 cm design
¶ With an embedded area of just 19.8 cm, it is ideal for
installation in areas with limited space. Plus, the
ceiling panel is just 1.5 cm deep, so it doesn’t impose
on the interior design of the room.
Auto-flap system and long-life filter
¶ The ceiling panel features an auto-flap system that
automatically sets the perfect flap angle to much the
cooling or heating operation. And with the long-life
filter, you don’t need to worry about maintenance for
the first 2,500 hours.
¶ Built-in high performance drain pump.
3-10. 1-Way air discharge semi-con-
cealed slim type
SLR93GH, SLR123GH
SLR183GH, SLR253GH
1492_T_I
3. Outline of Indoor Units
1493_T_I
Celing panel
Celing
Side cover
Hanging bolt
Installation
¶ Easy Installation and Maintenance
Unit position can be adjusted by simply detaching
the side covers of the ceiling panel, so there’s no
need to dismantle the entire panel.
To Next Page
