Sanyo VPC-CS1 Service Manual

– 13 –
A
C
C
D
A
D
B
B
3
2
6
5
4
21
22
19
24
18
23
25
27
28
B
A
20
20
7
26
29
8
1
12
9
15
14
10
16
17
11
13
When assembling,
tighten the screws order.
A → B
1. Screw 1.7 x 2
2. Two screws 1.7 x 4
3. Assy, cover LCD back
4. Spacer earth LCD
5. Remove the solder.
6. Spacer VF1
7. Connector (CN172)
8. Two screws 1.7 x 3
9. Assy, joint
10. Spacer MR
11. Holder joint
12. Spacer joint (removed after assembly)
13. Dec joint
14. Assy, wire VF1 & CP1
15. Assy, magnet
16. Screw 1.7 x 2.5
17. TB1 board
18. Connector (CN173)
19. Connector (CN171)
20. Two screws 1.7 x 3.5
21. Erath LCD
22. Spacer erath LCD
23. VF1 board
24. Spacer MIC
25. Holder LCD
26. Spacer LCD
27. LCD
28. Unit cover LCD fron
29. Magnet
2-3. REMOVAL OF TB1 BOARD, VF1 BOARD AND LCD
12
13
9
12
14
12
When assembling
