Specifications
Basic
plus
Model BP 211D BP 301S
Weighing range structure DualRange SuperRange
Weighing capacity g 40/80/210 303
Readability mg 0.01/0.01/0.1 0.1
Tare range (by subtraction) mg –210 –303
Reproducibility (standard deviation)* mg ≤0.02/≤0.05/≤0.1 ≤0.2
Linearity mg ≤ ±0.03/≤±0.1/≤±0.2 ≤±0.3
Response time (average) s ≤12/3 ≤3
Allowable ambient operating temperature °C +5 …+40
Operating temperature range °C +10… +30
Sensitivity drift within +10 °C ... +30 °C /°C ≤±1·10
–6
Pan size mm Ø 80
Weighing chamber height (effect. dimens.) mm 225
Dimensions (WxDxH)
– Balance mm 204x297x332 204x297x332
– Electronics box mm 134x 51x155 –
Net weight, approx. kg 6.6 5.5
External calibration weight
(of at least accuracy class...) g 200 (E2) 200+100 (E2)
Power requirements V~ Via AC adapter: STNG 6/TNG 6, 230 VAC or 115 VAC,
–20%...+15% (IP 20 protection)
Frequency Hz 48– 63
Power consumption (average) VA 16 maximum; 8 average
Hours of operation with fully charged YRB 05 Z
external battery pack, approx. h 25 32
Built-in interface RS-232C-S/V24-V28; 7-bit; parity: even, mark, odd, space;
transmission rates: 150 … 19,200 baud;
1or 2 stop bits; software/hardware handshake
Standard features/equipment supplied:
Dust cover x x
AC adapter, varies acc. to country x x
Built-in calibration weight x x
Level indicator x x
Hanger for below-balance weighing x x
* = standard deviation of the reproducibility acc. to DIN 8120, Part 3
68
