Model CPA26P CPA225D CPA324S CPA224S CPA124S CPA64 CPA64-WDS
Weighing capacity g 5/21 40/100/220 320 220 120 64 64
Readability mg 0.002/0.01 0.01/0.01/0.1 0.1 0.1 0.1 0.1 0.1
Tare range (subtractive) g –21 –220 –320 –220 –120 –64 -64
Repeatability <±mg 0.004 0.02/0.05/0.1 0.2 0.1 0.1 0.1 0.1
1
)
(std. deviation)
Linearity <±mg 0.008 0.03/0.1/0.2 0.3 0.2 0.2 0.2 0.2
1
)
Response time (average) s 10 < 6/3 < 3 < 2 < 2 < 2 < 2
1
)
Operating temperature
range °C +10 to +30°C (50° to 86°F)
Allowable ambient
operating temperature °C +5 to +40°C (41°F to 104°F)
Sensitivity drift within
+10… +30°C <±/K 1 ·10
–6
External calibration weight g 20 200 (E2) 200 + 200 (E2) 100 (E2) 50 (E2) 50 (E2)
(of at least accuracy class…) (E2) 100 (E2)
Net weight, approx. kg 7.6 7.6 6.5 6.5 6.5 6.5 4.1
Pan size (inner diameter)* mm 50 d 80 d 80 d 80 d 80 d 80 d 80 d
Pan surface* cm
2
20 64 64 64 64 64 64
Weighing chamber height mm 162 232 232 232 232 232 –
(from pan to cover)
Dimensions (W+D+H)
– Balance mm 213+ 213+342+340 213+342+340
213+342+92
342+270
– Electronics box mm 134+51+155 –––––
AC power source/ V~ AC adapter, 230 V or 115 V, +15%…–20%
Power requirements (protection rating IP20)
Frequency Hz 48 – 60
Power consumption VA maximum 16; typical 8
(average)
Approx. hours of operation
with the YRB05Z
rechargeable battery pack h 20 20 22 22 22 22 22
Selectable weight units Grams, carats, pounds, ounces, Troy ounces, Hong Kong taels,
Singapore taels, Taiwanese taels, grains, pennyweights, milligrams,
parts per pound, Chinese taels, mommes, Austrian carats, tola, baht and mesghal
Built-in interface RS-232/V24-V28
Format: 7-bit ASCII, 1 start bit, 1 or 2 stop bits
Parity: Mark, odd, even or space
Transmission rates: 150 to 19,200 baud
Handshake mode: Software or hardware
* Three-sided weighing pan: d = Diameter of inner circle.
The cross-hatched section can be fully utilized.
1
) These specifications were determined with the draft shield in place.
68
