71
Model CPA CPA CPA CPA CPA CPA CPA CPA
10001 8201 5201 34001S 34001P 16001S 12001S 34000
Weighing capacity kg 10 8.2 5.2 34 8/16/34 16 12 34
Readability (scale interval) g 0.1 0.1 0.1 0.1 0.1/0.2/0.5 0.1 0.1 1
Tare range (subtractive) kg –10 –8.2 –5.2 –34 –34 –16 –12 –34
Repeatability <±g 0.1 0.1 0.1 0.1 0.05/0.05/ 0.05 0.05 0.5
(std. deviation) 0.1
Linearity <±g 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.5
Response time (average) s < 1 < 1 < 1 < 2 < 2 < 2 < 2 < 1.5
Operating temperature range °C 10° to 30° (50° to 86°F)
Allowable ambient
operating temperature °C 0° to 40° (32° to 104°F)
Sensitivity drift
within 10° to 30°C <±/K 4 · 10
–6
4 · 10
–6
4 · 10
–6
2 · 10
–6
2 · 10
–6
2 · 10
–6
2 · 10
–6
2 · 10
–6
External calibration weight kg 5 (F1) 5 (F2) 2 (F2) 10 (F1) 10 (F2) 10 (F1) 10 (F1) 10 (F2)
(of at least accuracy class...)
Net weight, approx. kg 4.7 4.7 4.7 16 16 16 16 16
Weighing pan size mm
190+204 190+204 300+400 300+ 400 300+400 300+400 300+400
Dimensions (W+D+H) mm 213+ 213+ 213+ 313+ 313+ 313+ 313+ 313+
342+ 342+ 342+ 532+ 532+ 532+ 532+ 532+
90 90 90 120 120 120 120 120
AC power source/ V~ AC adapter STNG6, 230 V or 115 V,
power requirements +15% to – 20% (protection rating IP20)
Frequency Hz 48 – 60
Power consumption (average) VA maximum 16; typical 8
Approx. hours of operation
with a rechargeable
battery pack h 40 40 40 22 22 22 22 22
Selectable weight units Grams, kilograms, carats, pounds, ounces, Troy ounces,
Hong Kong taels, Singapore taels, Taiwanese taels, grains,
pennyweights, milligrams, parts per pound, Chinese taels, mommes,
Austrian carats, tola, baht and mesghal
Cable length between display
unit/weighing platform m – – – 1.2 1.2 1.2 1.2 1.2
Built-in interface RS-232C-S/V24-V28; 7-bit; parity: even, odd, mark, or space;
transmission rates: 150 to 19,200 baud; 1 or 2 stop bits;
software/hardware handshake
* Three-sided weighing pan: d = Diameter of inner circle.
The cross-hatched section can be fully utilized.
