Operating Instructions Cubis
®
MCA 31
Operating Design
Symbol Name Description
[Tare 1] button Stores the current weight value in the tare1 memory.
Tare 1
0.00 g
[Tare 1 Entry] button Opens an entry field for manually entering the tare1 value.
[Delete Tare 1] button Deletes the tare1 memory.
[Start] button Starts the selected application.
[Quit] button Quits the active application and opens
thePrintMemorydisplay.
[Confirm] button Confirms the current display and initializes the next step.
[Save] button Saves the weight value and sends it to the print memory.
[Print memory] button Opens the Print Memory display.
[Print] button If the Print Memory is displayed: Exports the saved print
orders via the integrated data interfaces.
[Connect] button Checks the connection to a connected printer and prints
atest page.
[Connector] button Checks the connection to the respective connector.
[Ionizer] button Only for semi-microbalances and analytical balances
withintegrated ionizers: Starts an ionization process.
g
[Unit change] button − Toggles between the weight units and the resolution.
− Accesses the “Unit change” function menu.
[Restart] button If an application is active: Deletes the saved values
andrestarts the application.
[Report] button If an application is active, e.g. density determination:
Displays a report about the progress of the application.
[Result report] button If an application is active, e.g. density determination:
Displays a report about the result of the application.
[Export] button − Creates files depending on the context.
− Releases the exported files, e.g., PDF or HTML files,
viaaconnector.
[Help] button Displays descriptions of the menu and parameter contents,
e.g., weighing characteristics | functions or printing concept.
