72 Operating Instructions Cubis
®
MCA
System Settings
7.7.11 Parameters in the “Connections / Interfaces / Serial Communication over Network”
(Ethernet) Menu
Parameter Setting Values Explanation
Protocol Off* Deactivates the serial transmission via Ethernet.
SBI Enables SBI communication. The data is output to a PC or control
unit. Enables the use of ESC commands from a PC to control the
basic balance functions with ASCII protocol.
SICS Enables SICS communication. The data is output to a PC or control
unit. Enables the use of commands from a PC to control the basic
balance functions with SICS protocol.
xBPI Extended range of commands to control numerous balance
functions with binary protocol for direct communication with
theweighing module.
QAPP direct Allows for the data input and output via a QAPP direct connection
from a network server or USB stick to a data processing program.
Only the special QAPPs, which are started by a task, can use the
interface for their purposes of input and output.
miniSICS Enables miniSICS communication. The data is output to a PC or
control unit. Enables the use of commands from a PC to control
the basic balance functions with the miniSICS protocol.
Log
communication
On Activates the automatic data recording for this interface
(onlyactivate for test purposes).
Off* Deactivates the automatic data recording for this interface.
Port User input Saves the entered port number for the Ethernet interface.
* Factory setting
7.7.12 Parameters in the “Connections / Interfaces / COM-RS232 Interface” Menu
Parameter Setting Values Explanation
Protocol Off* Deactivates the RS232 connection.
SBI Enables SBI communication. The data is output to a PC
orcontrol unit. Enables the use of ESC commands from a PC
tocontrol the basic balance functions with ASCII protocol.
SICS Enables SICS communication. The data is output to a PC or control
unit. Enables the use of commands from a PC to control the basic
balance functions with SICS protocol.
xBPI Extended range of commands to control numerous balance
functions with binary protocol for direct communication with
theweighing module.
