Interface Port
Purpose
Your balance/scale is equipped with an
interface port for connection to a computer
or other peripheral device.
You can connect a computer to change,
start and/or monitor the functions of the
balance/scale and the application
programs.
Features
Type of interface: Serial interface
Operating mode: Full duplex
Standard: RS-232
Transmission rates:
600, 1200, 2400, 4800, 9600
and 19,200 baud
Parity: odd, even, none
Number of data bits: 7 or 8 bits
Character format:
1 start bit, 7-bit ASCII, parity,
1 or 2 stop bits
Handshake:
For 2-wire interface:
software (XON/XOFF)
For 4-wire interface:
hardware (CTS/DTR)
Data output format of the balance/scale:
16 or 22 characters
Factory Settings
Transmission rate:
1200 baud (menu code 1. 5. 1. 4)
Parity: Odd (1. 5. 2. 3)
Stop bits: 1 stop bit (1. 5. 3. 1)
Handshake:
Handshk. Hardware, (1. 5. 4. 2)
Operating mode: Printer (1. 5. 6. 2)
printing: Man.With Manual after stability
(1. 6. 1. 2)
Preparation
See “Pin Assignments” and
“Pin Assignment Chart”
Identification of Non-Verified Digits
To have non-verified digits (when “e # d”)
automatically identified on the printout,
set the following parameters: Communica-
tion: Printer (menu code 1. 5. 6. 2)
Non-verified digits are marked by square
brackets [ ].
43
