Commands (Data Input Format)
You can connect a computer to your balance/scale to send commands via the balance/scale
interface port for controlling balance/scale functions and applications. The commands sent
are control commands and may have different formats. Control commands consist of up to
13 characters. Each character must be transmitted according to the settings configured in
the operating menu for data transmission.
Format for Control Commands
Format 1: Esc ! CR LF
Format 2: Esc ! # _ CR LF
Esc: Escape (optional) CR: Carriage return
!: Command character LF: Line feed (optional)
_: Underline
Command character Format 1:
! Meaning
K Ambient conditions: very stable
L Ambient conditions: stable
M Ambient conditions: unstable
N Ambient conditions: very unstable
O Block keys
P r key (print, auto print; activate or block)
R Unblock keys
S Restart/self-test
T w key
W Calibration/adjustment (depending on the menu setting)
Z Internal calibration/adjustment*
Command character Format 2:
!# Meaning
f0_ Function key b
f1_ Function key q
f2_ Function key u
s3_ c key
x1_ Print balance/scale model
x2_ Print weighing cell serial number
x3_ Print software version
* = only on models with built-in motorized calibration weight
47
