7
Selecting the Line Voltage (Mains Voltage)
(Optional)
Use the following original AC adapters for selecting
the line voltage:
– AC adapter TNG8 order no. 6971951 (universal)
or
– AC adapter TNG8 order no. 6971952 (for the U.K.)
Use the switch to toggle between 230 V and 115 V
Leveling the Balance
Level the balance any time you set it up in
a new location. Use only the 2 front feet of the
balance for leveling.
Turn the 2 rear feet until they are in position
(only on models AZ3102, AZ1502)
Turn the 2 front feet as shown here in the illustration
until the air bubble is centered in the level indicator
> In most cases, this will require several adjustment steps
Anti-theft Locking Device
To protect against theft, use the mounting lug on
the rear panel of the balance.
Secure the balance at the place of installation,
for example with a chain or a lock
