Operating Instructions PMA 35001-X 11
t Place the weighing pan on the balance.
Connecting the Device to AC Power
Power is supplied via a Sartorius AC adapter. Make sure that the voltage rating
printed on this unit matches the voltage at the place of installation.
If the stated supply voltage or the plug design of the power cord does not comply
with the standard you use, please inform your nearest Sartorius representative or
your supplier. Use only original Sartorius adapters: A list of permitted models can
be found in the Accessories (Options) chapter on page 28. The use of cables from
other manufacturers, even if these units have a registered approval rating from
anational testing laboratory, requires the consent of a qualified technician.
When operating the scale in Zone 1 potentially explosive areas, follow the
current standards and regulations for the installation of devices in Zone 1.
In order to connect the equipment to the power supply, use a correctly installed
wall outlet with a protective grounding conductor (PE) and a fuse of a maximum
16 A.
t Connection of the power supply outside of the potentially explosive
atmosphere or mechanically secured (refer to “Safety Information" documents).
t Plug the power cord on the Sartorius AC adapter into the wall outlet (mains).
Observe all warnings and safety precautions.
See also: “Safety Instructions” documents.
Connection of Peripheral Devices:
When installing the device in potentially explosive atmospheres of Zone 1,
connectors may only be plugged in or disconnected in a currentless/dead-voltage
state.
Disconnect the scale from the power line before connecting peripheral devices
(printer, PC) to the interface port of the device.
t When connecting peripheral devices (printer, PC) to the scale's interface port,
make sure that the screws on the data plug are securely tightened.
Observe all warnings and safety precautions.
See also: “Safety Instructions” documents.
Installation
