3
Pos. Description
1 Load receptor
2 Weigh cell
3 Electronics unit
4 Interface port
5 LED: RxD/DC jack (yellow)
Pos. Description
6 Female connector for optional display unit
7 Female connector for weigh cell
8 LED: TxD (red)
9 DC jack
10 Menu access switch
11 Hook for below-cell weighing
! Users should never alter any of the other screws!
Overview of Equipment
1
2
11
1
2
11
1
2
3
4
5
6
9 8 7
10
Models WZA224-L, WZA523-L: Model WZA8202-L:
