6
AC Power Supply
AC Adapter Assembly
! Fatal electric shocks can be caused by use of the incorrect power plug adapter or
improper use of the power plug adapter.
– Attach the country-specific power plug adapter to the AC adapter. The power plug
adapter must be suitable for the wall outlet at the installation location.
– Do not insert the power plug adapter into the socket without an AC adapter.
Item number
on packaging
Power supply/country-
specific power plug
adapter (packed in PE
bag with printed country
code, e.g. EU)
Illustration (from left to right)
YEPS01-15VOH Power supply with
connection cable
YEPS01-PS1 USA and Japan (US+JP)
Europe (EU)
United Kingdom (UK)
YEPS01-PS2 India (IN)
South Africa (ZA)
Argentina (AR)
Brazil (BR)
YEPS01-PS3 Australia (AU)
Korea (KR)
China (CN)
§ Select the country-specific power plug adapter. The power plug adapter must be
suitable for the wall outlet at the installation location.
§ Push the power plug adapter into the AC adapter’s holder. The ribbed button must be
facing forward.
§ Push the power plug adapter all the way in until it audibly engages.
§ Check that the power plug adapter is firmly locked in place. To do this, gently pull on
the power plug adapter.
$ If the power plug adapter cannot be moved then it is locked in place.
Removing the Power Plug Adapter
§ Press on the ribbed button from above and slide the power plug adapter backward.
§ Push the power plug adapter out of the AC adapter and remove it.
