Mounting Plate Dimensions for Model WZA8202-L
15
22.2 32.5 47.5 49.2
119
162.7 184.2
230 245
15
11.84
20.5
29.16
65.9
92.5
67.5
117.5
119.1
170
185
2 x45°(4x)
All dimensions are given in millimeters
