6 Installer Manual SATEL
INT-KLCDK / INT-KLCDL / INT-KLCDS – 6.12 (or later);
INT-KSG – 1.02 (or later).
The INTEGRA 256 Plus control panel supports the INT-KSG keypads with firmware
version 2.00 or newer (the INT-KSG keypads with older firmware versions will not be
identified).
The keypads are available in a variety of color options for the enclosure, display and key
backlight. The color variant is indicated by the additional designation in the keypad name
(e.g. INT-KLCD-GR – green display and key backlight; INT-KLCD-BL – blue display and key
backlight).
Features of the INT-TSG, INT-TSI and INT-KSG keypads are described in a separate
manuals, delivered with these keypads.
3.1 Features of keypads with mechanical keys
Display 2 x 16 characters with backlight.
LEDs indicating the status of the partitions and the system.
Backlit keys.
Built-in sounder.
2 programmable hardwired zones:
– support for NO and NC detectors;
– support for Single EOL and Double EOL configuration.
Tamper protection in 2 ways – cover removal and tearing enclosure from the wall.
RS-232 port (PIN-5 socket) for administration of the security alarm system by means of a
computer with the G
UARD
X program installed.
4. Expansion modules
The expansion modules allow you to not only increase the number of available zones and
outputs (wired and wireless), but also enhance the system with additional functionality.
Not all of the following modules meet the requirements of EN 50131 for Grade 3.
4.1 Modules to be connected to the keypad bus
CA-64 PTSA. Mimic board. Enables visualization of the status of the alarm system partitions
and zones. The control panels support the mimic boards with electronics version 1.4 (or
later) and firmware version 4.0 (or later).
ETHM-1. TCP/IP communication module. Enables reporting events as well as operating
and programming the control panel via the Ethernet network. The recommended
module version: 1.06 (or later).
INT-RS / INT-RS Plus. Interface for systems integration. Makes it possible to connect the
computer with the G
UARD
X program installed in the same way as to the LCD keypad,
report events through a special external device, or operate the control panel using
software other than that offered by SATEL.
Only INT-RS Plus interface is compatible with INTEGRA 256 Plus control panel.
