SATEL INTEGRA Plus 3
1. General
This manual applies to the control panels of the INTEGRA Plus series:
– INTEGRA 64 Plus
– INTEGRA 128 Plus
– INTEGRA 256 Plus
The manual also describes keypads compatible with the INTEGRA Plus control panels and
other devices that may be included in the security alarm system.
The INTEGRA Plus control panels meet the requirements of the following standards:
– EN 50131-1 Grade 3;
– EN 50131-3 Grade 3;
– EN 50131-6 Grade 3;
– EN 50130-4;
– EN 50130-5 Class II.
2. Features
System structure
 32 partitions.
 8 objects (subsystems).
Zones
 16 programmable hardwired zones on the control panel mainboard:
– support for NO and NC type detectors, as well as roller shutter and vibration detectors;
– support for Single EOL, Double EOL and Triple EOL configuration;
– programmable value of end-of-line resistors;
– several dozen zone types.
 Maximum number of programmable zones:
– up to 64 (INTEGRA 64 Plus);
– up to 128 (INTEGRA 128 Plus);
– up to 256 (INTEGRA 256 Plus).
Outputs
 16 programmable hardwired outputs on the control panel mainboard:
– 4 high-current outputs;
– 12 low-current outputs, OC type;
– over 100 functions;
– execution of custom control functions due to the possibility of programming complex
logic operations on the outputs.
 Maximum number of programmable outputs:
– up to 64 (INTEGRA 64 Plus);
– up to 128 (INTEGRA 128 Plus);
– up to 256 (INTEGRA 256 Plus).
 3 high-current outputs on the control panel mainboard with power supply output
functionality.
Communication buses
 Keypad bus for connecting up to 8 devices.
