SATEL INTEGRA Plus 33
 using the D LOAD X program, in the "Structure" window, "System" tab, after clicking on the
object name – a new partition will be created after you click on the "Add" button.
3.2.2 Programming partitions
You can program the partitions:
 using the keypad, in the service mode, by means of the functions available in the
P ARTITIONS submenu (S TRUCTURE S YSTEM  P ARTITIONS );
 using the D LOAD X program, in the "Structure" window, "System" tab, after clicking on the
partition name.
3.2.3 Partition parameters
Shown in square brackets is the parameter name as presented in the LCD keypad.
The user authorization can be based on a code, proximity card (125 kHz passive
transponder) or DALLAS iButton. In the description of the partition parameters only the
codes are taken into account, but the information also applies to the proximity cards
and DALLAS iButtons.
Partition name – individual name of partition (up to 16 characters).
Fig. 3. Example of partition settings in the D LOAD X program.
