40 Programming SATEL
disarmed. If the value 0 is programmed, control of this time is disabled. The time can be
programmed in hours or minutes.
It is recommended that you program the M
AX
.
NO VIOLATION TIME
parameter, since it will
provide an additional supervision of the detector connected to the zone.
3.3.5 Zone types
0. E
NTRY
/E
XIT
– a delayed zone combining two functions:
entry – violation of the zone starts entry delay counting in the partition and turns on delay
for the 3.
I
NTERIOR DELAYED
type zones;
exit – violation of the zone during exit delay countdown is equivalent to the partition exit.
1. E
NTRY
– violation of the zone starts entry delay counting in the partition and turns on delay
for the 3.
I
NTERIOR DELAYED
type zones.
2. D
ELAYED
– a delayed-action zone with optional signaling of delay countdown in keypads.
3. I
NTERIOR DELAYED
– the zone operates as a delayed one when:
– violation of another zone has triggered the entry delay countdown in the partition;
– the delay will be activated using the INT-ENT entry keypad (see the INT-SCR
multifunction keypad manual);
– arm mode type 2 or 3 is active and the D
ELAY IN
2&3
TYPE ARMING
option is enabled for
the zone.
In other situations, the zone will act as an instant one.
4. P
ERIMETER
– instant zone, which is already armed during exit delay countdown.
5. I
NSTANT
– instant zone.
6. E
XIT
– violation of the zone during exit delay countdown is equivalent to the partition exit.
7. D
AY
/N
IGHT
– if disarmed, the zone will signal violation acoustically in keypads and on
the 9. DAY
A
LARM
, 12. S
ILENT ALARM
and 116. I
NTERNAL
S
IREN
outputs. When armed, the
zone acts as the 5. I
NSTANT
zone.
8. E
XTERIOR
– a zone with alarm verification: zone violation will start counting the surveillance
time – if a second violation takes place during this time, an alarm will be triggered. If the
S
URVEILLANCE TIME
is not programmed (the value 0 is entered), the alarm will be generated
upon the first violation.
9. 24
H
T
AMPER
– permanently armed zone, intended for the tamper circuits. The zone
violation will additionally cause a trouble condition.
10. 24
H
V
IBRATION
– permanently armed zone, intended for working with vibration detectors.
If the partition includes the 10. 24
H
V
IBRATION
zone, starting the procedure of arming
from the LCD keypad will initiate a test of vibration detectors (the 39. T
EST VIBRATION
DETECTORS
output is activated and the countdown of time remained to the test end is
running).
11. 24
H
C
ASH MACHINE
– permanently armed zone, intended for protection of a cash machine.
12. PANIC-
AUDIBLE
– permanently armed zone, intended for operating the panic buttons.
13. PANIC-
SILENT
– permanently armed zone, intended for operating the panic buttons.
Violating the zone will trigger a silent alarm.
14. M
EDICAL
–
B
UTTON
15. P
ERSONAL EMERGENCY
The zone types 14 and 15 trigger alarm signaled in the LCD keypads and on the 12. S
ILENT
ALARM
outputs. The names of zones and codes of events from these zones are consistent
with the Contact ID reporting format.
