SATO CG4 Series User Manual

Section 6: General Specifications
CG4 Series Operator Manual Page 6-7
6.2 OPTIONAL ACCESSORIES SPECIFICATIONS
CUTTER SPECIFICATIONS
Media Type Non-adhesive paper and Label
Media Size
Pitch : 0.87” to 11.8” (22 to 300 mm)
Pitch including liner : 0.98” to 11.93” (25 to 303 mm)
Width : 0.87” to 4.21” (22 to 107 mm)
Width including liner : 0.98” to 4.33” (25 to 110 mm)
Thickness 0.0024” to 0.0074” (0.06 to 0.19) mm
Self-diagnosis function Cutter error detection
Durability More than 300,000 cuts
DISPENSER SPECIFICATIONS
Media Type
Label only
* Some restrictions may apply to some label types depending on the substrate,
adhesive, paper size, and environment. Refer to SATO representative on the
labels to be used.
* Perforated liner and split liner cannot be used.
* Peel end labels
Media Size
Pitch : 0.86” to 3.93” (22 to 100 mm)
Pitch including liner : 0.98” to 4.05” (25 to 103 mm)
Width : 0.86” to 4.21” (22 to 107 mm)
Width including liner : 0.98” to 4.33” (25 to 110 mm)
Thickness 0.0024” to 0.0074” (0.06 to 0.19 mm)
Sensor Type Dispenser sensor (Reflective type)
LINERLESS (NONSEPA) KIT SPECIFICATIONS
Media Type Micro-perforated Linerless (Nonsepa) Label
Media Size
Pitch : 0.98” to 3.93” (25 to 100 mm)
Width : 0.98” to 4.33” (25 to 110 mm)
Thickness 0.0024” to 0.0074” (0.06 to 0.19 mm)
Media Winding direction Face-out
Roll and core Diameter Maximum outer diameter: 5.04” (128 mm) with Inner core diameter: 1.5” (40 mm)
Sensor Type Label sensor (Reflective type)
Label issuing mode Continuous mode, Tear-off mode
