SATO GL408e - Page 27

27
ESC+TM
ESC TM Parameter Hexadecimal
code
<1B>16 <54>16<4D>16 X
Initial value Nil
When power switch is
OFF
The set parameter is not maintained.
Valid range within item The set parameter becomes invalid.
Valid range
and term of
command
Valid range between
items
The set parameter becomes invalid.
[Function]
This is a Graphic function specifying the print of EPC trade mark on a tag label.
[Format]
<TM>X
[Parameters]
X=[Logo ID No.]
1:
2:
[Coding Example1] [Coding Example2]
<A> <A>
<V>50<H>50<TM>1
<V>50<H>50<TM>2
<Z> <Z>
[Notes]
1. Rotation <%> and Enlargement <L> are also available.
2. Specify the command Enlargement <L> right before <TM> in case of its usage.
3. The original print area is,
W143XH101 dots for logo1
W202XH101 dots for logo2 (without the designation of enlargement)
4. When the parameter X is left blank, the logo 1 will be printed.
EPC Trade Mark Print
