SATO GL408e User Manual

RFID KIT USER GUIDE
GL 4xxe Series
For printer models:
Read this User Guide before and during the operation of the
above accessory. Keep this Guide handy for future reference.
www.satoamerica.com
9001173A

SATO GL408e Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Print Resolution	203 dpi
Max Print Width	104 mm (4.09 inches)
Interfaces	Serial (RS232C)
Optional Interfaces	Wireless LAN (IEEE 802.11b/g)
Barcodes	Yes
Supported Barcode Types	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Codabar, MSI, Plessey, GS1-128, RSS-14, PDF417, Data Matrix, QR Code, MaxiCode
Media Type	Roll-fed
Media Thickness	0.06 mm to 0.19 mm (0.002 inches to 0.0075 inches)
Roll Outer Diameter	127 mm (5 inches) max
Core Diameter	76 mm
Ribbon Length	450 m (1476 feet) max
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Operating Humidity	25% to 85% RH, non-condensing
Storage Humidity	10% to 90% RH, non-condensing

Summary

1 General

Important Information

Provides essential setup information for your new SATO product.

FCC Warning and Notice

Covers FCC compliance for digital devices and potential radio frequency interference issues.

1.2 Explanation of Symbols

Warning, Caution, and Note Symbols

Explains the meaning of warning, caution, and note symbols used in the manual.

Overview

Manual Organization

Details the structure of the manual, outlining its main sections and topics.

1. Introduction to the RFID Configuration Options

RFID Menu Settings Overview

Covers RFID reader, tag type, error handling, communication retry, and overstrike style settings.

Custom Tag Configuration and Calibration

Details custom tag settings, power levels, data fields, calibration, and auto inlay locator.

Admin User Menu Items

Explains menu items visible when Admin User is enabled for authorized personnel.

Requesting an RFID Report

Procedure to print a summarized RFID report with validator data.

2. RFID Command Specification

EPC Code Write Command Details

Defines the EPC Code Write command, its parameters, and coding examples.

EPC Code Read Command Details

Defines the EPC Code Read command, its format, return status, and examples.

Sequential Numbering Command

Details the Sequential Numbering command, its parameters, and coding examples.

3. GL RFID Coupler Design

Coupler Positions and Adjustment Procedures

Describes coupler positions and the process for adjusting coupler position using the handle.

4. Adjusting the Coupler Position

Using the Coupler Handle and Indicator

Explains how to use the coupler handle and position indicator for alignment.

4. Error Messages

RFID Error Messages and Solutions

Lists RFID encoder error messages, their explanations, and suggested solutions.

Troubleshooting

Common RFID Troubleshooting Scenarios

Provides solutions for common RFID issues like communication failure and tag errors.
