Step Step 35
å
Fasten the DRAWER SIDES (D211, D32, D36, D37, D34, and D35) to the DRAWER
BACKS (D78, D77, and D74). Use eight BLACK 1-9/16" FLAT HEAD SCREWS (30S).
å
NOTE: The small drawer and drawer will only use one SCREW on each side. Be sure to use
the top hole.
å
Slide the DRAWER BOTTOMS (D708 and D716) into the grooves in the DRAWER
SIDES (D211, D32, D36, D37, D34, and D35) and DRAWER BACKS (D78, D77, and D74).
å
Repeat this step for the small right drawer using the DRAWER SIDES (D46 and D47),
DRAWER BACK (D76), and DRAWER BOTTOM (D958). The small right drawer will use two
SCREWS on each side.
Be sure the grooves in each
part line up with each other
on the inside of the drawer.
D716
D716
D708
D211
D211
Groove
Groove
Groove
Finished
surface
Finished
surface
Finished
surface
D35
D74
D34
D37 D77
D36
D32
D78
D78
D32
D36
D77
D37
D34
D74
D35
Use top hole
Use top hole
417714www.sauder.com/services
Page 41
BLACK 1-9/16" FLAT HEAD SCREW
(12 used in this step)
30S
To Next Page
