SawStop 10” Industrial Cabinet Saw 3
Table of Contents
Using Your Saw 27
1. Adjusting the Blade Height: 27
2. Adjusting the Blade Tilt Angle: 27
3. Turning on Main Power and Starting the Motor: 28
4. System Status Codes: 30
5. Using the Saw in Bypass Mode: 33
6. Using the Blade Guard: 34
7. Using the Riving Knife: 35
8. Using the Miter Gauge: 35
9. Cross-Cutting: 37
10. Rip Cutting: 38
11. Changing the Brake Cartridge: 40
What to do if the SawStop Safety System Activates 45
Making Adjustments to Your Saw 46
1. Aligning the Table: 46
2. Aligning the Blade Elevation Assembly: 50
3. Aligning the Blade to the Tilt Axis: 52
4. Adjusting the Elevation Limit Stops: 56
5. Adjusting the Tilt Limit Stops and Tilt Angle Indicator: 58
6. Adjusting the Table Insert: 60
7. Aligning the Riving Knife and Spreader to the Blade: 62
8. Adjusting the Quick-Release Clamp: 64
9. Adjusting the Tilt Gearing: 65
10. Adjusting the Miter Gauge: 66
Cabinet Saw Specications 67
