SawStop 10” Industrial Cabinet Saw 89
No. Description Part No. Qty.
1 Arbor Block CB104 172 1
2 Arbor CB104 173 1
3 M5x5x28 Key CB104 174 1
4 Main Arbor Bearing CB104 175 1
5 Electrode Shell CB104 176 1
6 M4x0.7x6 Phillips Head Screws CB104 177 2
7 BW-4 Lock Washer CB104 178 2
8 Second Arbor Bearing CB104 179 1
9 Arbor Spacer CB106 001 1
10 M20 External Retaining Ring CB104 181 3
11 Arbor Pulley CB104 182 1
12 M6x1x8 Set Screw CB104 183 2
13 Blade CB104 184 1
14 Arbor Washer CB104 185 1
15 Arbor Nut CB104 186 1
16 Pivot Shaft CB104 187 1
17 Bearing CB104 188 2
18 Double Pulley CB104 189 1
19 M5x0.8x10 Phillips Head Screw CB104 190 2
20 Arbor Belt CB104 191 1
21 Motor Belt CB104 192 1
22 BW-5 Lock Washer CB104 193 1
23 Cable Mount CB104 194 1
24 Brake Positioning Bolt CB104 195 1
25 Wave Washer CB104 196 2
26 O-Ring CB104 197 1
27 M13.5x28x2 Washer CB104 198 1
28 M10 External Retaining Ring CB104 199 2
29 Barrel Nut CB104 200 1
30 Cartridge Bracket Link CB104 201 1
31 Cartridge Bracket Back Plate CB104 202 1
32 Cartridge Bracket Face Plate CB104 203 1
33 Cartridge Cable CB104 204 1
34 M8x1.25x35 Hex Head Bolt CB104 205 2
35 Spacer CB104 206 3
36 M8.2x15.4 Washer CB104 207 3
37 M8x1.25 Lock Nut CB104 208 4
38 M6x1x12 Hex Head Bolt CB104 209 1
39 M6x1 Nut CB104 210 1
40 M8x1.25x35 Phillips Pan Head Bolt CB104 211 1
41 Spacer CB104 212 1
Arbor Assembly Parts List
