76 SawStop 10” Industrial Cabinet Saw
Featherboard Construction
This diagram illustrates a typical featherboard. Featherboards
should be constructed from good quality wood that is free of
knots. Use Featherboards to help keep the material being cut in
contact with the table, and to help prevent kickback. Do not use
featherboards when cutting with the miter gauge.
1” squares.
Featherboard should be approximately 3/4” thick.
