Saia-Burgess Controls AG
User Manual Standby System │ Document 27-645 │ Edition ENG 02 │ 2017-04-26
PCD3.T668 Standby RIO
Standby System Overview
1-11
1
1.6.2 Technical Data
Property PCD3.T668
Number of inputs/outputs 64 in base unit, extensible to 256
I/O-module slots 4 in base unit, extensible to 16
I/O-modules supported PCD3.Exxx, PCD3.Axxx, PCD3.Bxxx, PCD3.Wxxx
Max. number of RIO stations 128
Protocol for data transfer Ether-S-IO
Ethernet connection 10/100 Mbit/s, full-duplex, auto-sensing, auto-crossing
Default IP conguration
IP address: 192.168.10.100
Subnet mask: 255.255.255.0
Default gateway: 0.0.0.0
USB port for conguration and diagnostics yes
Program memory 128 kByte
Web server for conguration and diagnostics yes
Web server for user pages yes
On-Board le system for web pages and data 512 kByte
BACnet® or
LonWorks® no
On-Board interrupt inputs 2
On-Board RS-485 interface yes
Special modules for I/O-slot 0 only* PCD3.F1xx
for I/O-slots 0…3*
(up to 4 modules)
PCD3.H1xx counter
PCD3.F26x DALI
PCD3.F27x M-Bus
S-Web alarming/trending no
Watchdog no
Real-time clock no
Software clock (not battery-powered) yes, synchronized by the Manager
Battery no
*see manual 26-857
