SBE SB-36 OPERATION MANUAL
SYM PART NUMBER DESCRIPTION
D5 8000-00010-020 Diode, 1N60
D6 8000-00010-020 Diode, 1N60
D7 8000-00010-020 Diode, 1N60
D8 8000-00010-020 Diode, 1N60
D9 8000-00010-020 Diode, 1N60
D10
8000-00010-020
Diode, 1N60
D205 8000-00010-020 Diode, 1N60
D206
8000-00010-020
Diode, 1N60
L601 8000-00010-039 Choke, RFC
L602 8000-00010-039 Choke, RFC
T9 8000-00010-038 Transformer, 9 MHz
T9A 8000-00010-038 Transformer, 9 MHz
T10 8000-00010-038 Transformer, 9 MHz
T11 8000-00010-038 Transformer, 9 MHz
T12
8000-00010-038
Transformer, 9 MHz
TR6 8000-00010-018 Transistor, 2SK30
TR7
8000-00010-017
Transistor, 2SK30
TR8 4804-00003 Integrated Circuit, µA-703
TR9 8000-00010-018 Transistor, 2SK30
TR50 8000-00010-002 Transistor, 2SC458
TR51 8000-00010-018 Transistor, 2SK30
TR52 8000-00010-019 Transistor, 2SA495
TR53 8000-00010-019 Transistor, 2SA495
VC1 8000-00010-037 Capacitor, Variable, 30pF
VR5 8000-00010-023 Resistor, Variable, 500Ω
VR5N 8000-00010-027 Resistor, Variable, 100KΩ
8000-00010-040 Filter, Crystal, 9 MHz, Upper
8000-00010-041 Filter, Crystal, 9 MHz, Lower
8000-00010-046 Filter, Crystal, 9 MHz, CW
8000-00010-042 Socket for RL1
8000-00010-242 Filter, Crystal, CW
NoobowSystems Lab. Tomioka, Japan 2003 http://www.noobowsystems.com/ Page 39 / 56
