SBE SB-36 OPERATION MANUAL
FEP-502: DSB SSB AMPLIFIER AND NOISE BLANKER PC BOARD
SYM PART NUMBER DESCRIPTION
C22 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C23 8000-00010-036 Capacitor, Fixed, Ceramic, 1000pF, 50V
C24 8000-00010-032 Capacitor, Fixed, Styrol, 22pF, 50V
C25 8000-00010-010 Capacitor, Fixed, Ceramic, 0.02µF, 50V
C26 8000-00010-010 Capacitor, Fixed, Ceramic, 0.02µF, 50V
C26A 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C26B 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C26C 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C26D 8000-00010-034 Capacitor, Fixed, Electrolytic, 10uf, 25V
C26E 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C26F 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C26G 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C26H 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C26I 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C26J 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C26L 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C26M 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C26N 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C26P 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C26Q
8000-00010-004
Capacitor, Fixed, Ceramic, 0.01µF, 50V
C37 8000-00010-010 Capacitor, Fixed, Ceramic, 0.02µF, 50V
C38 8000-00010-010 Capacitor, Fixed, Ceramic, 0.02µF, 50V
C601 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C602 8000-00010-028 Capacitor, Fixed, Ceramic, 5pF, 50V
C602A 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C604 8000-00010-028 Capacitor, Fixed, Ceramic, 5pF, 50V
C605
8000-00010-004
Capacitor, Fixed, Ceramic, 0.01µF, 50V
C608 8000-00010-034 Capacitor, Fixed, Electrolytic, 10µF, 25V
C609
8000-00010-005
Capacitor, Fixed, Ceramic, 0.1µF, 50V
C610 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C611 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C612 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C614
8000-00010-005
Capacitor, Fixed, Ceramic, 0.1µF, 50V
C624 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C632 8000-00010-030 Capacitor, Fixed, Ceramic, 100pF, 50V
C671 8000-00010-036 Capacitor, Fixed, Ceramic, 1000pF, 50V
D1 8000-00010-020 Diode, 1N60
D2 8000-00010-020 Diode, 1N60
D3 8000-00010-020 Diode, 1N60
D4
8000-00010-020
Diode, 1N60
