FEP-501: MICROPHONE AMPLIFIER SIDE TONE OSCILLATOR PC BOARD
SYM PART NUMBER DESCRIPTION
C1 8000-00010-009 Capacitor, Fixed, Electrolytic, 47µF, 25V
C2 8000-00010-003 Capacitor, Fixed, Ceramic, 330pF, 50V
C3 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16v
C4 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16v
C5 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16v
C6 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C7 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16v
C8 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C9 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16v
C10 8000-00010-008 Capacitor, Fixed, Electrolytic, 22µF, 25v
C11 8000-00010-008 Capacitor, Fixed, Electrolytic, 22µF, 25V
C12 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16v
C13 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16v
C14 8000-00010-010 Capacitor, Fixed, Ceramic, 0.02µF, 50V
C15 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C16 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16v
C17 8000-00010-006 Capacitor, Fixed, Mylar, 0.01µF, 50V
C18 8000-00010-006 Capacitor, Fixed, Mylar, 0.01µF, 50V
C19 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
RL4 8000-00010-015 Relay, 12 VDC
TR1 8000-00010-002 Transistor, 2SC458
TR2 8000-00010-002 Transistor, 2SC458
TR3 8000-00010-002 Transistor, 2SC458
TR4 8000-00010-001 Transistor, 2SC367
TR5 8000-00010-002 Transistor, 2SC458
VR2 8000-00010-011 Resistor, Variable, 10kΩ
VR3 8000-00010-012 Resistor, Variable, 100kΩ
