SBE SB-36 OPERATION MANUAL
FEP-504 CRYSTAL OSCILLATOR PC BOARD
SYM PART NUMBER DESCRIPTION
L2 8000-00010-093 Coil, Oscillator, 28 MHz
L3 8000-00010-094 Coil, Oscillator
L4 8000-00010-094 Coil, Oscillator
L5 8000-00010-095 Coil, Oscillator
L6 8000-00010-095 Coil, Oscillator
VC2 8000-00010-097 Capacitor, Variable, 30pF
VC3 8000-00010-097 Capacitor, Variable, 30pF
VC4 8000-00010-097 Capacitor, Variable, 30pF
VC5 8000-00010-097 Capacitor, Variable, 30pF
VC6 8000-00010-097 Capacitor, Variable, 30pF
VC7 8000-00010-097 Capacitor, Variable, 30pF
VC8 8000-00010-097 Capacitor, Variable, 30pF
VC9 8000-00010-097 Capacitor, Variable, 30pF
X1 8000-00010-098 Crystal, 44.0 MHz
X2 8000-00010-099 Crystal, 43.5 MHz
X3 8000-00010-100 Crystal, 43.0 MHz
X4 8000-00010-101 Crystal, 42.5 MHz
X5 8000-00010-102 Crystal, 35.5 MHz
X6 8000-00010-103 Crystal, 28.5 MHz
X7 8000-00010-104 Crystal, 21.5 MHz
8000-00010-096 Socket, Crystal
