SBE SB-36 OPERATION MANUAL
FEP-504A HF CRYSTAL PRINTED CIRCUIT PC BOARD
SYM
PART NUMBER
DESCRIPTION
VC1 8000-00010-084 Capacitor, Fixed, Ceramic, Trimmer, 30pF
VC3 8000-00010-084 Capacitor, Fixed, Ceramic, Trimmer, 30pF
VC4 8000-00010-084 Capacitor, Fixed, Ceramic, Trimmer, 30pF
VC5 8000-00010-084 Capacitor, Fixed, Ceramic, Trimmer, 30pF
VC5A 8000-00010-084 Capacitor, Fixed, Ceramic, Trimmer, 30pF
VC6 8000-00010-084 Capacitor, Fixed, Ceramic, Trimmer, 30pF
VC6A 8000-00010-084 Capacitor, Fixed, Ceramic, Trimmer, 30pF
VC7 8000-00010-084 Capacitor, Fixed, Ceramic, Trimmer, 30pF
VC8 8000-00010-084 Capacitor, Fixed, Ceramic, Trimmer, 30pF
VC9 8000-00010-084 Capacitor, Fixed, Ceramic, Trimmer, 30pF
X1 8000-00010-216 Crystal, 44.0 MHz
X2 8000-00010-215 Crystal, 43.5 MHz
X3 8000-00010-211 Crystal, 43.0 MHz
X4 8000-00010-213 Crystal, 42.5 MHz
X5 8000-00010-212 Crystal, 35.5 MHz
X6 8000-00010-211 Crystal, 28.5 MHz
X7 8000-00010-210 Crystal, 21.5 MHz
8000-00010-228 Socket, Crystal, HC-25U
8000-00010-243 Printed Circuit Board, FEP-504A
