SBE SB-36 OPERATION MANUAL
FEP-505 VOX AND ANTI-TRIP PC BOARD
SYM
PART NUMBER DESCRIPTION
C77 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16v
C77A 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16v
C78 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16v
C78A 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16v
C79 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16v
C79A 8000-00010-009 Capacitor, Fixed, Electrolytic, 47µF, 25V
C639 8000-00010-113 Capacitor, Fixed, Ceramic, 5000pF, 50V
C640 8000-00010-113 Capacitor, Fixed, Ceramic, 5000pF, 50V
C641 8000-00010-007 Capacitor, Fixed, Electrolytic, 10µF, 16V
C642 8000-00010-113 Capacitor, Fixed, Ceramic, 5000pF, 50V
D12 8000-00010-020 Diode, 1N60
D13 8000-00010-020 Diode, 1N60
D14 8000-00010-020 Diode, 1N60
D15 8000-00010-020 Diode, 1N60
TR12 8000-00010-002 Transistor, 2SC458
TR13 8000-00010-002 Transistor, 2SC458
TR13A 8000-00010-002 Transistor, 2SC458
TR14 8000-00010-105 Transistor, 2SC374
TR15 8000-00010-002 Transistor, 2SC458
VR501 8000-00010-112 Resistor, Variable, 50kΩ
VR502 8000-00010-112 Resistor, Variable, 50kΩ
NoobowSystems Lab. Tomioka, Japan 2003 http://www.noobowsystems.com/ Page 44 / 56
