SBE SB-36 OPERATION MANUAL
FEP-506 CARRIER OSCILLATOR PC BOARD
SYM
PART NUMBER DESCRIPTION
C84 8000-00010-121 Capacitor, Fixed, Mica, 100pF, 50V
C87 8000-00010-122 Capacitor, Fixed, Mica, 200pF, 50V
C89 8000-00010-119 Capacitor, Fixed, Mica, 27pF, 50V
C90 8000-00010-120 Capacitor, Fixed, Mica, 47pF, 50V
C91 8000-00010-010 Capacitor, Fixed, Ceramic, 0.02µF, 50V
C643 8000-00010-119 Capacitor, Fixed, Mica 27pF, 50V
C650 8000-00010-004 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C651 8000-00010-004 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C652 8000-00010-004 Capacitor, Fixed, Ceramic, 0.1µF, 50V
RL3 8000-00010-015 Relay, 12 VDC
T13 8000-00010-124 Transformer, 9 MHz
T14 8000-00010-124 Transformer, 9 MHz
TR17 8000-00010-002 Transistor, 2SC458
TR19 8000-00010-002 Transistor, 2SC458
TR20 8000-00010-002 Transistor, 2sC458
VC201 8000-00010-123 Capacitor, Variable, 30pF
8000-00010-126 Plug, 11-Pin
FEP-507 AF POWER AMPLIFIER PC BOARD
SYM
PART NUMBER DESCRIPTION
C85A 8000-00010-116 Capacitor, Fixed, Electrolytic, 220µF, 16V
C95 8000-00010-009 Capacitor, Fixed, Electrolytic, 47µF, 25V
C96 8000-00010-115 Capacitor, Fixed, Electrolytic, 47µF, 16V
C97 8000-00010-114 Capacitor, Fixed, Electrolytic, 4.7µF, 16V
C98A 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C98B 8000-00010-005 Capacitor, Fixed, Ceramic, 0.1µF, 50V
C99 8000-00010-004 Capacitor, Fixed, Ceramic, 0.01µF, 50V
C100 8000-00010-009 Capacitor, Fixed, Electrolytic, 47µF, 25V
C101 8000-00010-114 Capacitor, Fixed, Electrolytic, 4.7µF, 16V
D17 8000-00010-109 Diode, 1S155
D18 8000-00010-021 Diode, 10D1
D19 8000-00010-021 Diode, 10D1
TR22 8000-00010-107 Transistor, 2SC495
TR23 8000-00010-108 Transistor, 2SA496
TR24 8000-00010-106 Transistor, 2SC733GR
TR25 8000-00010-019 Transistor, 2SA495
VR10 8000-00010-111 Resistor, Variable, 10kΩ
VR11 8000-00010-161 Resistor, Variable, 1kΩ
