IPM25 User Manual
16
HOLD Button
The hold button allows the user to freeze the display when it is pressed. When pressed again the display returns to it’s
normal operating mode. When in hold mode the display will flash and the hold LED will be lit, to ensure that this
feature is not accidentally turned on without the user noticing.
The hold feature can not be used when the IPM25 is in either peak or trough hold mode.
GROSS/NET Button
The gross/net button, when pressed, toggles between the gross and net display values. This enables the user to zero
the display (by putting the IPM25 into net mode) and displaying the change in display value from that point.
This is useful for certain weighing applications where a tare weight exists, which can be removed by putting the IPM25
into net mode.
SHUNT CAL Button
The shunt calibration button, when pressed, puts an internal 100k resistor across the –ve excitation and –ve signal
of the sensor, generating a simulated output from the sensor, therefore giving a simulated display value. This can be
pressed immediately after the sensor has been calibrated with the IPM25 and noted down for later reference. The
value noted can be used to get an idea of the calibration accuracy at a later date, or for checking the integrity of the
sensor and sensor cabling.
The shunt calibration resistor can be changed to suit specific requirements. It is suggested that a 15ppm ±0.1%
tolerance resistor is used.
PEAK Button
When pressed this button puts the IPM25 into peak mode. This will display the highest display reading and hold it on
the display until it is reset or a higher value is reached. To reset the peak display, press the peak and trough buttons
simultaneously. In peak mode it is possible to capture peaks at a rate of up to 25Hz. To turn off the peak mode, press
the peak button.
TROUGH Button
When pressed this button puts the IPM25 into trough mode. This will display the lowest display reading and hold it on
the display until it is reset or a lower value is reached. To reset the trough display, press the peak and trough buttons
simultaneously. In trough mode it is possible to capture troughs at a rate of up to 25Hz. To turn off the trough mode,
press the peak button.
