38
1
6
2a
3a 3b
4b4a
7
5a 5b
2b
1
Mount skamol plate 1 with the 2 screws
(To be continued on next page)
MAINTAINANCE
SWEEPING THE CHIMNEY AND CLEANING STOVE
Follow national and local regulations for sweeping the chimney. We recommend having the stove cleaned regularly by a chimney
sweep.
Before cleaning the stove and sweeping the flue pipe and chimney, we recommend removing the baffle plates.
Make sure the stove is cold before starting maintenance or repair work.
CHECKING THE STOVE
Scan A/S recommends that you check your stove thoroughly after sweeping/cleaning. Check all visible surfaces for cracks.
Check that all joints are tight and that the gaskets are correctly seated. Worn or deformed gaskets should be replaced.
SERVICING
Apart from having the chimney swept, your wood-burning stove does not require any regular maintenance. However, we do re-
commend servicing at least once every two years. We recommend that the stove is thoroughly serviced at least once every two
years by a qualified fitter. The service should include the following:
¬ Lubricate hinges using copper grease
¬ Check the gaskets. Replace any that are broken or have gone soft
¬ Check the combustion chamber bottom and riddling grate
¬ Check heat-insulating materials
COMBUSTION CHAMBER LINING
Slight cracks can appear in the combustion chamber lining due to moisture or sudden heating/cooling. These cracks have no
influence on the output or lifetime of your stove. However, if the lining starts to crumble and fall out, you must replace it.
The combustion chamber lining is not covered by the warranty.
FIRE BOX LINING
¬ 7 skamol plates (1-5b) ¬ 2 screws ¬ 1 baffle plate (6) ¬ 1 pin for the baffle plate (7)
