39
3a 3b
5a 5b
6
7
2 3
4
5
6
Mount skamol plate 4a and 4b
When skamol plates 1-4 are inserted, it should look like this.
Make sure that the two baffles are placed identically
Mount skamol plate 5a and 5b
Mount the baffle plate (6) with the accompanying pin (7)
Mount skamol plate 2a and 2b Mount skamol plate 3a and 3b
