SCAN 68 Series - Page 7

7
371
192
179
1110
1205
350
175
1222
500
250
B A
C
C
DIMENSION SKETCH SCAN 68-5, 68-6, 68-11 AND 68-12 (PORTAL)
A
Centre rear outlet
B
Height to the beginning of the
connecting piece at top outlet
C
Centre of fresh air intake
All measurements are in millimeters
